Brand: TP-LINK

Category: Network - Consumer / Line Filters & Splitters

SKU: MC1400

Description: TP-Link MC1400 19' 2U Rackmount Chassis for 14-Slot Media Converters, Redundant Power Supply, Hot-Swappable, Mounted,Two Cooling Fans 14 bays to house up to 14 media converters Optional redundant power supply to ensure non-stop reliable operation Hot-Swappable; easy & quick replacement of converter and power supply Mounted two cooling fans for better ventilation The TL-MC1400 14-slot 19' rack-mount chassis is designed specially to accommodate 14 TP-LINK media converters. The centralized power supply makes the installation neat and sharp. The hot-swappable redundant power supply (purchase separately) design comes with chases allows uninterrupted installation and maintenance jobs. Two cooling fans are installed to stabilize the performance and extend the lifetime Together with MC series Gigabit or Fast Ethernet media converters, TL-MC1400 is the ideal solution for your media conversion network.

Brand: TP-LINK

Category: Network - Consumer / Line Filters & Splitters

SKU: MC200CM

Description: Complies with IEEE 802.3ab and IEEE 802.3z Provides switch configuration of Force /Auto transfer mode for FX port Extends fiber distance up to 0.55km

Brand: TP-LINK

Category: Network - Consumer / Line Filters & Splitters

SKU: MC210CS

Description: TP-Link MC210CS Gigabit Single-Mode Media Converter Extends fiber distance up to 15km Works at 1000Mbps in Full-Duplex mode for both TX port and FX port Supports auto MDI/MDIX for TX port Provides switch configuration of Force /Auto transfer mode for FX port. Extends fiber distance up to 15km Easy-to-view LED indicators provide status to monitor network activity easily External power supply What This Product Does The MC210CS is a media converter designed to convert 1000BASE-LX/LH fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-LX/LH standards, the MC210CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC210CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on both transmitting and receiving data. Other features of this module include the ability to be used as a stand alone device (no chassis required) or with TP-LINK´s 19´´system chassis, Auto MDI/MDI-X for TX port, and front panel status LEDs. The MC210CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 15 kilometers. MEDIA CONVERTER & MODULE Standards and Protocols IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x Basic Function Full Duplex Flow Control (IEEE 802.3x) Extends fiber distance up to 15km Ports 1 1000M SC/UPC port 1 1000M RJ45 port (Auto MDI/MDIX) Wave Length 1310nm Network Media 1000BASE-FX Single-mode Fiber Network Media 1000BASE-T UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) LED Indicators PWR, LINK, RX Dimensions (W*D*H) 3.7*2.9*1.1 in. (94.5*73.0*27.0 mm) Power Supply External Power Adapter Max Power Consumption 5.5W Safety & Emission FCC, CE, RoHS Environment Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing

Brand: TP-LINK

Category: Network - Consumer / Line Filters & Splitters

SKU: MCRP100

Description: TP-Link TL-MCRP100 100-240V Redundant Power Supply Module for TL-MC Series Media Converter Up to 102 watts output power Output over-voltage/short circuit/over-current protection What this product does The TP-LINK Redundant Power Supply Module TL-MCRP100 is an AC-input and DC-output power supply module. It can convert 100-240V 50/60Hz input voltage into 9.5VDC output with rated wattage of 102W. The power supply module supports output over-voltage/short circuit/over-current protection. TL-MCRP100 is applicable to 14-Slot Rackmount Chassis TL-MC1400. REDUNDANT POWER SUPPLY AC Power Input 100-240V~ 50/60Hz 3A DC Power Output 9.5V/9.5A Dimensions 210*130*70 mm Environment Operating Temperature: 0℃~60℃ (32℉~140℉) Storage Temperature: -35℃~85℃ (-31℉~185℉) Operating Humidity: 20%~90%RH non-condensing Storage Humidity: 10%~95%RH non-condensing
