Brand: Maxhub

Category: Peripherals / Displays / Monitor Accessories

SKU: OPS72A-i5

Description: Maxhub OPS72A-i5 12th Gen i5, 8G+256G

Features

• Slot in PC Module for IFP
• Compatible with Classic, Vogue & Transcend
• 8th Generation Intel Core i7
• DDR4 16GB RAM
• M.2 256GB SSD
• 3x USB 3.0 / 1x HDMI Out / Gigabit LAN
• Windows 10

Brand: Maxhub

Category: Peripherals / Displays / Monitor Accessories

SKU: OPS72A-i7

Description: Maxhub OPS72A-i7 12th Gen i7, 16G+256G

Features

Processor:

• Processor family: Intel® Core™ i7
• Processor manufacturer: Intel
• Processor generation: 11th gen Intel® Core™ i7

Memory:

• Internal memory: 16 GB
• Internal memory type: DDR4-SDRAM

Ports & interfaces

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
• USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
• HDMI ports quantity: 1
• Ethernet LAN (RJ-45) ports: 1
• Microphone in: _
• Line-out: _

Weight & dimensions

• Width: 202 mm
• Depth: 30 mm
• Height: 133,5 mm
• Weight: 750 g
• Package width: 267 mm
• Package depth: 72 mm
• Package height: 192 mm
• Package weight: 970 g

Operational conditions

• Operating temperature (T-T): -10 - 50 °C
• Storage temperature (T-T): -20 - 60 °C
• Operating relative humidity (H-H): 10 - 90%
• Storage relative humidity (H-H): 10 - 90%

Network

• Ethernet LAN: _

Storage

• Total storage capacity: 256 GB
• Optical drive type: _
• Storage media: SSD
• Total SSDs capacity: 256 GB
• Number of SSDs installed: 1
• SSD capacity: 256 GB

Software

• Operating system installed: Windows 10
• Operating system architecture: 64-bit

Packaging content

• Display included: _

Design

• Product colour: Black
• Cable lock slot: _

Graphics

• Discrete graphics card: _
• On-board graphics card: _
• Discrete graphics card model: Not available
• On-board graphics card model: Intel® UHD Graphics

Performance

• Product type: Mini PC
• Trusted Platform Module (TPM): _

Brand: Maxhub

Category: Peripherals / Displays / Monitor Accessories

SKU: SW19

Description: MAXHUB SW19 PCAP Stylus Kit - 2pcs in one package, for capacitive screen

Brand: Maxhub

Category: Peripherals / Displays / Monitor Accessories

SKU: TCP10M

Description: MAXHUB Touch Controller, 10.1, 1920(H)?1080(V)?10-point capacitive touch recognition?Compatible with MAXHUB IFP V6 Above?Android 10 operation system.

Features:

• Touch Screen - 10-point capacitive touch recognition
• Power Over Ethernet - A single cable carries both power and data to reduce clutter
• Cable Free Paring - Connect to your Maxhub Display/Videobar wirelessly
• Sleek Design - Control options are clear and accessible
• Compatibility - Compatible with MAXHUB IFP/Commercial Display/VideoBar S10Pro/S15 family

Specifications:

Display

• Size: 10.1 inch
• Resolution: 1920 (H) x 1080 (V)
• Refreshing Frequency: 60Hz
• NTSC: 55%
• Back Light Unit'' ELED
• Brightness with glass (typ): 280cd/m2
• Life span: 15000 Hours

Operating System

• System Version: Android 10.0
• RAM: 4G
• ROM: 16G
• CPU: A53x4
• GPU: Mali-G52

Brand: Maxhub

Category: Peripherals / Displays / Monitor Accessories

SKU: ST23G

Description: MAXHUB Trolley For Conference - Maxmium load 100KG, avaliable for 65'' - 86''

Features

• Model: ST23G
• Dimension (L × W × H): 1205 × 639 × 1605 mm
• Dimension with package (L × W × H): 1558 × 920 × 145 mm
• Net Weight: 32.5 kg
• Gross Weight: 34.2 kg
• Max. Load: 100 kg
• Max. Load Size: 55 ~ 98 inch
• Caster Size: 2.5 inch
• Color: Black
• VESA Hole Pitch: 800 × 600 mm

Specifications

Accessory

• Screw accessory package × 1
• Installation guide × 1
• Wall mount bracket: No
• Display bracket: No

Environmental Condition

• Operating temperature: 0°C ~ 40°C
• Operating humidity: 10% ~ 90% RH
• Storage temperature: −20°C ~ 40°C
• Storage humidity: 10% ~ 90% RH

Brand: Maxhub

Category: Peripherals / Displays / Monitor Accessories

SKU: U50

Description: MAXHUB All in one video conference terminal, camera, 50MP dual lens, 12 microphone array, 2*10W speaker, NT98692, RK3562

Features

• 100MP Dual-Camera System – Ultra-high resolution with 125° wide-angle view.
• AI-Powered Video – Auto Framing, Speaker Tracking, Intelligent Focus, Smart Gathering, Video Fence.
• Studio-Grade Audio – Dual 15W stereo speakers delivering full-frequency sound.
• 12-Microphone Array – 8m pickup range with AI noise reduction, echo cancellation, and anti-reverberation.
• Privacy Protection – Electric automatic lens shutter.
• Cloud Management – Remote monitoring and control via MAXHUB Pivot.
• Seamless Connectivity – USB 3.0, RJ45 for expansion mics.

Specifications

• Camera: Dual 50MP, 6x digital zoom, 125° HFOV.
• Audio: 2 × 15W speakers, 12-mic array (100 Hz–12 kHz).
• Connectivity: USB 3.0 Type-B, DC In, RJ45 (expansion mics).
• Power: Max. 85W, DC 19V.
• Size & Weight: 650.8 × 76.6 × 95.7 mm; 2.68 kg.
• Accessories: Power adapter, USB cable (3m), remote control, mounting kit.

Brand: Maxhub

Category: Peripherals / Displays / Monitor Accessories

SKU: TCP33T

Description: MAXHUB Universal Touch Console

Features

• One‑Cable Technology: Easy and flexible installation with a single cable between the IFP and touch console
• Motion Sensor: Automatically sleeps or wakes the room display based on inactive/active HDMI video signals to save energy
• Content Sharing: Share content on the IFP using a USB‑C cable
• PoE Power: Supports standard power supply and data transmission

Specifications

• TCP33T Universal Console: × 1
• UD20A Interface Converter: × 1
• PoE Adapter: × 1
• Package Dimension (4 pieces): 590 × 440 × 280 mm / 23.23 × 17.32 × 11.02 inch
• Package Weight: 4.6 kg / 10.14 lbs

Display

• Size: 11.6 inch
• Resolution: 1920 × 1080
• Refresh Rate: 60 Hz
• Back Light Unit: ELED
• Brightness With Glass: 250 nits (Min.), 300 nits (Max.)
• Lifespan: ≥ 20000 hours

Touch System

• Type: Capacitive touch
• Surface Treatment: Anti-fingerprint, Anti-glare

Sensor

• Motion Sensor: PIR sensor for automatic wake-up
• Ultrasound Emitter: Supported

Environmental Condition

• Operating Temperature: 0°C ~ 40°C / 0°F ~ 104°F
• Operating Humidity: 10% ~ 90% RH
• Storage Temperature: -20°C ~ 60°C / -4°F ~ 140°F
• Storage Humidity: 10% ~ 90% RH
• Altitude: Below 5000 m

Physical Specification

• Product Dimension (L × W × H): 278 × 164 × 82 mm / 11 × 6.4 × 3.2 inch
• Product Weight: 1.16 kg / 2.56 lbs

I/O Port

• USB‑C (Content Sharing): × 1
• RJ45: For connecting PoE adapter or MAXHUB XBoard V7 Teams Room
• Kensington Slot: × 1

Standard Accessories

• Power Cord: × 3
• Ethernet Cable (7.5 m / 24.6 ft): × 2
• UD20A Interface Converter: × 1
• PoE Adapter (Output: 54V, 0.56A, 30.24W): × 1
• Type‑C Cable (1.8 m / 5.9 ft): × 1
• Quick Start Guide: × 1
• Screwdriver: × 1

Brand: Maxhub

Category: Peripherals / Displays / Monitor Accessories

SKU: V50

Description: MAXHUB XBar V50 Dual-eyes 4K Microsoft Teams Rooms MDEP Videobar Android system 8GB RAM 64GB ROM / Dual-eyes 100MP 4K Camera HFOV 125? / AP30 x1

Features

• 100MP Camera System: Dual-lens camera with 125° HFOV. Ultra-high-resolution camera system redefines image clarity and spatial adaptability
• BYOD Mode: Connect to your PC with a single USB cable for BYOD meeting
• AI-Powered Technology: Auto Framing, Speaker Tracking, Smart Gathering, Intelligent Focus
• AI Noise Reduction: Built-in 12 MEMS microphone array with AI noise reduction
• Studio-Grade Dual Speakers: Dual 15W, Stereo Sound, Full Frequency
• Cloud Device Management: Remotely monitor device status through cloud-based service (MAXHUB Pivot) via an internet connection

Specifications

Package Contents

• XBar V50 (With Standard Accessories) × 1
• Panel AP30 (With Accessories) × 1

Environmental Condition

• Operating Temperature: 0°C ~ 40°C / 0°F ~ 104°F
• Storage Temperature: -20°C ~ 60°C / -4°F ~ 140°F
• Operating Humidity: 10% ~ 90% RH
• Storage Humidity: 10% ~ 90% RH
• Altitude: Below 5000 m

Physical Specification

• Package Dimensions (L×W×H): 770 × 257 × 275 mm / 30.3 × 10.1 × 10.8 in
• Gross Weight: 9.98 kg / 22.0 lb

Content Sharing

• Teams (In Meeting): 1080p@30
• Local Sharing (Type-C): 4K@30
• Local Sharing (HDMI): 4K@30

Device Management

• Microsoft Device Management Platform (Teams Admin Center / Intune / Pro Management Portal)
• MAXHUB Pivot

XBar V50

Operating System

• MDEP Supported
• Android 13

Camera

• Camera Quantity: 2
• Pixel: 50MP × 2
• Sensor: 1/1.55 inch
• Aperture: F/2.4
• Resolution & Frame Rate:
  • H.264 / MJPEG: 3840×2160, 2560×1440, 1920×1080, 1280×720, 1024×576, 960×540, 800×600, 640×360
  • YUY2: 1920×1080, 1280×720, 640×360
• Zoom: 6x Digital Zoom
• Field of View: 130° (D), 125° (H), 50° (V)
• Privacy Shutter: Electric and automatic lens shutter

AI Features (Camera)

• Auto Framing
• Speaker Tracking
• Intelligent Focus
• Smart Gathering
• Video Fence
• Audio Fence

Input/Output Ports

• USB 3.0 Type-B × 1 (PC connection)
• USB 2.0 Type-A × 1 (debug/update)
• HDMI Out × 2 (up to 4K@60Hz, CEC supported)
• HDMI In × 1 (up to 4K@60Hz)
• Audio In × 1 (third-party input)
• Audio Out × 1 (third-party output)
• RJ45 (Internet) × 1
• RJ45 (M Link) × 1 (expansion device)
• DC In × 1 (19V power supply)

Power Adapter

• AC Input: 100–240 V
• DC Output: 19V / 4.5A

Audio

Speaker

• Quantity: 2
• Sound Channel: 2.0
• Total Power: 15W + 15W
• Max Sound Pressure: 83 dB SPL@1W/1M
• Frequency Range: 80 Hz ~ 20 KHz

Microphone

• Quantity: 12-mic array
• Pickup Range: 8 m
• Frequency Range: 20 Hz ~ 16 KHz
• Sensitivity: -36 ± 1 dBFS
• Sampling Rate: 48 KHz
• Expansion: Supports 2 expansion microphones

AI Features (Audio)

• Noise Reduction
• Echo Cancellation
• Anti-Reverberation
• AEC (Acoustic Echo Cancellation)
• ANS (Automatic Noise Suppression)
• AGC (Automatic Gain Control)
• Full-duplex

Standard Accessories

• Power Adapter × 1
• AC Cable (1.5 m / 4.9 ft) × 1
• HDMI Cable (3 m / 9.8 ft) × 2
• Ethernet Cable (3 m / 9.8 ft) × 1
• Mounted Components (ADA Standard) × 1

Physical Specification

• Product Dimensions (L×W×H): 650.8 × 76.6 × 95.7 mm / 25.6 × 3.01 × 3.77 in
• Package Dimensions (L×W×H): 750 × 136 × 246 mm / 29.5 × 5.4 × 9.7 in
• Net Weight: 2.8 kg / 6.17 lb
• Gross Weight: 6.0 kg / 13.23 lb

Network

• Wi-Fi: Wi-Fi 6, 2×2 MIMO
• Wi-Fi Protocol: 802.11 a/b/g/n/ac/ax
• Working Band: 2.4 GHz + 5 GHz
• Bluetooth: 5.2 + BLE
• Network Speed: 1000 Mbps

Panel AP30

Display

• Size: 11.6 inch
• Resolution: 1920 × 1080
• Refresh Rate: 60 Hz
• Backlight Unit: ELED
• Brightness With Glass: 250 nits (Min.), 300 nits (Max.)
• Life Time: ≥ 20000 hours

Touch System

• Type: Capacitive touch
• Surface Treatment: Anti-fingerprint, Anti-glare

Sensor

• Motion Sensor: PIR sensor for automatic wake-up

Accessories

• Type-C Cable (1.5 m / 4.92 ft) × 1
• Ethernet Cable (7.5 m / 24.61 ft) × 1
• Screwdriver × 1
• Power Adapter × 1
• AC Cable (1.5 m / 4.9 ft) × 1

Input/Output Ports

• RJ45 (INTERNET) × 1
• RJ45 (EXT) × 1
• DC In × 1
• Type-C (INGEST) × 1
• USB 2.0 (Pairing Wireless Dongle) × 1

Power

• Power Input: 19V DC 4.5A
• Power Output: Type-C PD 65W (Max.)

Physical Specification

• Product Dimensions (L×W×H): 278 × 164 × 82 mm / 11 × 6.4 × 3.2 inch
• Product Weight: 1.16 kg / 2.56 lb
• Package Dimensions (1 pcs): 570 × 246 × 101 mm
• Package Dimensions (4 pcs): 590 × 440 × 280 mm
• Package Weight (1 pcs): 3.12 kg

Operating System

• MDEP Supported
• Android 13

Brand: Maxhub

Category: Peripherals / Displays / Monitor Accessories

SKU: V70

Description: MAXHUB XBar V70 Qua-eyes 4K Microsoft Teams Rooms MDEP Videobar Android system 8GB RAM 64GB ROM / Quad-eyes 200MP 4K Camera HFOV 125?+ Dual tele cam / AP30 x 1

Features

• 200MP Camera System Ultra-high-resolution camera system redefines image clarity and spatial adaptability
• Quad Sight Lens Ultra-wide 125° HFOV. Dual telephoto lens for close-up tracking
• AI-Powered Technology Auto Framing, Speaker Tracking, Smart Gathering, Intelligent Focus
• AI Noise Reduction Noise Reduction, Echo Cancellation, Anti-Reverberation, AGC Algorithm
• Extended Capability Can connect to both third-party device and exclusive MAXHUB device
• Studio-Grade Dual Speakers Dual 20W, Stereo Sound, Full Frequency, Quad Passive Radiator
• BYOD Mode Connect to your PC with a single USB cable for BYOD meeting
• Cloud Device Management Remotely monitor device status through cloud-based service (MAXHUB Pivot) via an internet connection

Specifications

Package Contents

• XBar V70 (With Accessories) × 1
• Panel AP30 (With Accessories) × 1

Device Management

• Microsoft Device Management Platform
  • Microsoft Teams Admin Center
  • Intune
  • Pro Management Portal
• MAXHUB Pivot

Physical Specification

• Package Dimensions: 985 × 290 × 275 mm / 38.8 × 11.4 × 10.8 in
• Gross Weight: 11.7 kg / 25.79 lb

Environmental Condition

• Operating Temperature: 0°C ~ 40°C / 0°F ~ 104°F
• Storage Temperature: -20°C ~ 60°C / -4°F ~ 140°F
• Operating Humidity: 10% ~ 90% RH
• Storage Humidity: 10% ~ 90% RH
• Altitude: Below 5000 m

Content Sharing

• Teams (In Meeting): 1080p@30
• Local Sharing (Type-C): 4K@30
• Local Sharing (HDMI): 4K@30

XBar V70

Camera

• Quantity: 4
• Pixel: 50MP × 4
• Sensor: 1/1.55 inch
• Aperture: F/2.4
• Resolution & Frame Rate:
  • H.264 / MJPEG: 3840×2160, 2560×1440, 1920×1080, 1280×720, 1024×576, 960×540, 800×600, 640×360
  • YUY2: 1920×1080, 1280×720, 640×360
• Zoom: 8x Hybrid Zoom
• Wide Camera FOV: 130° (D), 125° (H), 50° (V)
• Telephoto Camera FOV: 52° (D), 42° (H), 32° (V)
• Privacy Shutter: Electric and automatic lens shutter

AI Features (Camera)

• Auto Framing
• Speaker Tracking
• Intelligent Focus
• Smart Gathering
• Video Fence

Audio

Speaker

• Quantity: 2
• Sound Channel: 2.0
• Total Power: 20W + 20W
• Max Sound Pressure: 88 dB (+/-2 dB) SPL@1W/0.5m
• Frequency Range: 80 Hz ~ 20 KHz

Microphone

• Quantity: 16-mic array
• Pickup Range: 10 m
• Frequency Range: 20 Hz ~ 16 KHz
• Sensitivity: -36 ± 1 dBFS
• Sampling Rate: 48 KHz
• Expansion: Supports 2 expansion microphones

AI Features (Audio)

• Noise Reduction
• Echo Cancellation
• Anti-Reverberation
• AGC Algorithm
• Full-Duplex

Input/Output Ports

• USB-A (2.0) × 1 (Firmware update and debug)
• HDMI In × 1 (Up to 4K@60Hz)
• HDMI Out × 2 (Up to 4K@60Hz, CEC supported)
• USB-B 3.0 (Device) × 1 (BYOD Mode)
• DC In × 1 (19V power supply)
• Audio In × 1 (Third-party audio input)
• RJ45 (Internet) × 1
• RJ45 (M Link) × 1 (Panel connection)
• RJ45 (Ext) × 1 (Expansion device connection)
• USB-A (3.0) × 1 (Firmware update and debug)
• Audio Out × 1 (Third-party audio output)

Standard Accessories

• Power Adapter × 1
• AC Cable (1.5 m / 4.9 ft) × 1
• HDMI Cable (3 m / 9.8 ft) × 2
• Ethernet Cable (3 m / 9.8 ft) × 1
• Mounted Components × 1

Physical Specification

• Product Dimensions: 840.6 × 117.6 × 104 mm / 33.1 × 4.6 × 4.1 in
• Package Dimensions: 962 × 169 × 246 mm / 37.9 × 6.7 × 9.7 in
• Net Weight: 4.3 kg / 9.7 lb
• Gross Weight: 7.0 kg / 15.4 lb

Power

• Power Adapter: AC 100–240 V Input, DC 19V/4.5A Output

Network

• Wi-Fi: Wi-Fi 6, 2×2 MIMO
• Wi-Fi Protocol: 802.11 a/b/g/n/ac/ax
• Working Band: 2.4 GHz + 5 GHz
• Bluetooth: 5.2 + BLE
• Network Speed: 1000 Mbps

Operating System

• MDEP Supported
• Android 13

Panel AP30

Display

• Size: 11.6 inch
• Resolution: 1920 × 1080
• Refresh Rate: 60 Hz
• Backlight Unit: ELED
• Brightness With Glass: 250 nits (Min.), 300 nits (Max.)
• Life Time: ≥ 20000 hours

Touch System

• Type: Capacitive touch
• Surface Treatment: Anti-fingerprint, Anti-glare

Sensor

• Motion Sensor: PIR sensor for automatic wake-up

Standard Accessories

• Type-C Cable (1.5 m / 4.92 ft) × 1
• Ethernet Cable (7.5 m / 24.61 ft) × 1
• Screwdriver × 1
• Power Adapter × 1
• AC Cable (1.5 m / 4.9 ft) × 1

Input/Output Ports

• RJ45 (Internet) × 1
• RJ45 (Ext) × 1
• DC In (Power) × 1
• Type-C (Ingest) × 1
• USB 2.0 (Pairing Wireless Dongle) × 1

Power

• Power Input: 19V DC 4.5A
• Power Output: Type-C PD 65W (Max.)

Physical Specification

• Product Dimensions (L×W×H): 278 × 164 × 82.4 mm / 11 × 6.4 × 3.2 inch
• Product Weight: 1.16 kg / 2.56 lb
• Package Dimensions (1 pcs): 570 × 246 × 101 mm
• Package Dimensions (4 pcs): 590 × 440 × 280 mm
• Package Weight (1 pcs): 3.12 kg

Operating System

• MDEP Supported
• Android 13

Brand: Maxhub

Category: Peripherals / Displays / Monitor Accessories

SKU: W70

Description: MAXHUB XBar W70 Qua-eyes 4K Microsoft Teams Rooms Windows Videobar 12thGen Intel 10-core i5 processor 16GB RAM 256GB ROM / Quad-eyes 200MP 4K Camera HFOV 125?+ Dual tele cam / TCP31T x 1

Features

• 200MP Camera System Ultra-high-resolution camera system redefines image clarity and spatial adaptability
• Quad Sight Lens Ultra-wide 125° HFOV. Dual telephoto lens for close-up tracking
• AI-Powered Technology Auto Framing, Speaker Tracking, Smart Gathering, Intelligent Focus
• AI Noise Reduction Noise Reduction, Echo Cancellation, Anti-Reverberation, AGC Algorithm
• Extended Capability Can connect to both third-party device and exclusive MAXHUB device
• Studio-Grade Dual Speakers Dual 20W, Stereo Sound, Full Frequency, Quad Passive Radiator
• BYOD Mode Connect to your PC with a single USB cable for BYOD meeting
• Cloud Device Management Remotely monitor device status through cloud-based service (MAXHUB Pivot) via an internet connection

Specifications

XBar W70 Kit

Package Contents

• XBar W70 (With Standard Accessories) × 1
• TCP31T Touch Console (With Standard Accessories) × 1

Optional Accessories

• Wireless Dongle WT13M or WT13S

Physical Specification

• Package Dimensions: 985 × 290 × 275 mm / 38.8 × 11.4 × 10.8 in
• Gross Weight: 14 kg / 30.86 lb

Device Management

• Control and Management: MAXHUB Pivot

Environmental Condition

• Operating Temperature: 0°C ~ 40°C / 0°F ~ 104°F
• Storage Temperature: -20°C ~ 60°C / -4°F ~ 140°F
• Operating Humidity: 10% ~ 90% RH
• Storage Humidity: 10% ~ 90% RH
• Altitude: Below 5000 m

Content Sharing

• Teams (In Meeting): 1080p@30
• Local Sharing (Type-C): 1080p@30
• Local Sharing (HDMI): 4K@30

XBar W70

General Information

• CPU: Intel® Core™ i5-1240P Processor
• Memory: 16 GB
• Storage: 256 GB
• Graphics: Intel® UHD Graphics for 12th Gen Intel® Processors

Camera

• Quantity: 4
• Pixel: 50MP × 4
• Sensor: 1/1.55 inch
• Aperture: F/2.4
• Resolution & Frame Rate:
  • H.264 / MJPEG: 3840×2160, 2560×1440, 1920×1080, 1280×720, 1024×576, 960×540, 800×600, 640×360
  • YUY2: 1920×1080, 1280×720, 640×360
• Zoom: 8x Hybrid Zoom
• Wide Camera FOV: 130° (D), 125° (H), 50° (V)
• Telephoto Camera FOV: 52° (D), 42° (H), 32° (V)
• Privacy Shutter: Electrical and automatic lens shutter

AI Features (Camera)

• Auto Framing
• Speaker Tracking
• Intelligent Focus
• Smart Gathering
• Video Fence

Audio

Speaker

• Quantity: 2
• Sound Channel: 2.0
• Total Power: 20W + 20W
• Max Sound Pressure: 88 dB (+/-2 dB) SPL@1W/0.5m
• Frequency Range: 80 Hz ~ 20 KHz

Microphone

• Quantity: 16-mic array
• Pickup Range: 10 m
• Frequency Range: 20 Hz ~ 16 KHz
• Sensitivity: -36 ± 1 dBFS
• Sampling Rate: 48 KHz
• Expansion: Supports 2 expansion microphones

AI Features (Audio)

• Noise Reduction
• Echo Cancellation
• Anti-Reverberation
• AEC (Acoustic Echo Cancellation)
• ANS (Automatic Noise Suppression)
• AGC (Automatic Gain Control)
• Full-duplex

Input/Output Ports

• USB 3.0 Type-A × 1 (Third-party audio input)
• USB 2.0 Type-A × 1 (Firmware update and debug)
• HDMI Out × 3 (Up to 4K@60Hz, CEC supported)
• HDMI In × 1 (Up to 4K@60Hz)
• RJ45 (Internet) × 1
• RJ45 (M Link) × 1 (BYOD wired connection)
• RJ45 (Console) × 1 (Touch console connection)
• RJ45 (Ext) × 1 (MAXHUB accessories)
• DC In × 1 (19V power input)

Standard Accessories

• Power Adapter × 1
• AC Cable (1.5 m / 4.9 ft) × 1
• HDMI Cable (3 m / 9.8 ft) × 2
• Ethernet Cable (3 m / 9.8 ft) × 1
• Ethernet Cable (7.5 m / 24.6 ft) × 1
• Mounted Components × 1

Physical Specification

• Product Dimensions: 840.6 × 117.6 × 104 mm / 33.1 × 4.6 × 4.1 in
• Net Weight: 5.0 kg / 11.0 lb

Power

• Power Adapter: AC 100–240 V Input, DC 19V/10A Output

Operating System

• Windows 11 IoT Enterprise SAC
• Application: Microsoft Teams Room

Network

• Wi-Fi: Wi-Fi 6, 2×2 MIMO
• Wi-Fi Protocol: 802.11 a/b/g/n/ac/ax
• Working Band: 2.4 GHz + 5 GHz
• Working Mode: STA
• Bluetooth: 5.2 + BLE
• Network Speed: 1000 Mbps

Touch Console TCP31T

Display

• Size: 11.6 inch
• Resolution: 1920 × 1080
• Refresh Rate: 60 Hz
• Backlight Unit: ELED
• Brightness With Glass: 250 nits (Min.), 300 nits (Max.)
• Life Time: ≥ 20000 hours

Touch System

• Type: Capacitive touch
• Surface Treatment: Anti-fingerprint, Anti-glare

Physical Specification

• Product Dimensions (L×W×H): 278 × 164 × 82.4 mm / 11 × 6.4 × 3.2 inch
• Product Weight: 1.16 kg / 2.56 lb

Sensor

• Motion Sensor: PIR sensor for automatic wake-up

Standard Accessories

• USB-C Cable (1.8 m / 5.9 ft) × 1
• Ethernet Cable (7.5 m / 24.6 ft) × 1
• Screwdriver × 1

Optional Accessories

• Wall-Mounted Kit (TCP30WM Bracket) × 1

Input/Output Ports

• RJ45 (To Bar) × 1
• USB-A 2.0 (For USB Audio accessories) × 1
• Type-C (Ingest) × 1
• RJ45 (M Link) × 1
• USB 2.0 (Pairing wireless dongle) × 1
• Audio Out (3.5 mm) × 1
