Brand: Gigabyte

Category: Motherboards / Accessories

SKU: THUNDERBOLTS 5

Description: Gigabyte CARD THUNDERBOLTS 5 1.0 add-in card​, Intel® JHL9580 Thunderbolt™ 5 controller​, Dual Thunderbolt™ 5 Ports, up to 80 Gb/s bi-directional Key Features •Intel® Thunderbolt™ 5 Certified add-in card​ •Intel® JHL9580 Thunderbolt™ 5 controller​ •Dual Thunderbolt™ 5 Ports (USB Type-C™)​ •Deliver up to 80 Gb/s bi-directional bandwidth, or up to 120Gb/s single-direction bandwidth. •Provides maximum support for DisplayPort™ 2.1 with 8K at 60Hz*​ •Daisy-chain up to 10 Devices (5 devices per port)​ •Support PD3.1 standard (up to 100W) * To enable DP2.1 functionality, specific cables are required. * THUNDERBOLTS 5 add-in card availability may vary based on local distribution.

Brand: Simplecom

Category: Motherboards / Accessories

SKU: EC412

Description: Simplecom EC412 Dual M.2 (B Key and M Key) to PCI-E x4 and SATA 6G Expansion Card EC412 is a PCI Express expansion card designed to add NGFF M.2 devices such as SSD onto existing PC motherboard. Dual M.2 slots support both PCI-E based M.2 device (M key, NVMe) to run via the faster PCI-E interface at up to 32Gbps, and legacy SATA based M.2 slot (B key) for connecting to a SATA III port. Features Connects one M.2 port (M key) into one PCI-E x4 interface Connects a second M.2 port (B key) into SATA 6G interface Supports two M.2 SSD simultaneously Supports PCI-E interface (M key) at up to 32Gbps Supports SATA interface (B key) at up to 6Gbps No driver installation required Specifications Interface: PCI Express X4 / SATA 6Gbps SSD Interface: M.2(NGFF) Module Key: B key (SATA-based), M key (PCI-E 4X-based, NVMe) Number of Drives: 2 Supported Type M.2 SSD: 2230, 2242, 2260 and 2280 Supported Length of M.2 SSD: 30mm, 42mm, 60mm, 80mm Important Note M key M.2 is for use with PCI-E (NVMe) SSD only, B key M.2 is for use with SATA SSD only. B key M.2 SSD requires SATA 7 pin cable connected to motherboard to function. NVMe M.2 SSD requires the use of Intel 9 series (Z97 H97 Z170 X99) or higher version chipset based motherboard with Windows 8 or higher operating system. It’s recommended to update your motherboard’s driver and BIOS to the latest version before install the Expansion Card. Package Contents 1x PCI Express Expansion Card 2x Mounting Screws 1x SATA Cable

Brand: Simplecom

Category: Motherboards / Accessories

SKU: EC412V2

Description: Simplecom EC412v2 NVMe and SATA M.2 SSD to PCIe x4 Expansion Card • One M Key M.2 slot for NVMe M.2 SSD • One B Key M.2 slot for SATA M.2 SSD • PCIe x4 interface, also compatible PCIe x8 or x16 slot • NVMe M.2 (M key) slot supports data transfer rate up to 64Gbps • SATA M.2 (B key) slot supports data transfer rate up to 6Gbps • Supports NVMe M.2 and SATA M.2 SSD simultaneously Simplecom EC412v2 NVMe and SATA M.2 SSD to PCIe x4 Expansion Card EC412v2 is a PCI Express expansion card designed to add M.2 SSD to an existing PC motherboard. This card provides two M.2 slots, offering flexible support for both NVMe or SATA based M.2 SSDs. The M Key M.2 slot, is dedicated to PCI-E based NVMe SSD, which utilize the high-speed PCI Express interface. This allows for significantly faster data transfer rates, with speeds reaching up to 64Gbps, making it ideal for demanding applications, large file transfers, and improving system responsiveness. The B Key M.2 slot, is designed for traditional SATA M.2 SSD. This slot connects to PC via a SATA connector, supporting data transfer rates of up to 6Gbps, which is suitable for more traditional storage needs. The expansion card offers the convenience of integrating both fast NVMe M.2 SSDs and traditional SATA M.2 SSDs simultaneously, making it an adaptable solution for upgrading and expanding storage on existing systems. Features • One M Key M.2 slot for NVMe M.2 SSD • One B Key M.2 slot for SATA M.2 SSD • PCIe x4 interface, also compatible PCIe x8 or x16 slot • NVMe M.2 (M key) slot supports data transfer rate up to 64Gbps • SATA M.2 (B key) slot supports data transfer rate up to 6Gbps • Supports NVMe M.2 and SATA M.2 SSD simultaneously Specifications • Model: EC412v2 • Interface: PCI Express x4, SATA 6Gbps • Number of Supported M.2 Drive: 2 • Module Key: B Key (for SATA M.2 only), M Key (for NVMe M.2 only) • PCIe Bandwidth: up to 32Gbps (PCIe 3.0), 64Gbps (PCIe 4.0) • SATA Bandwidth: up to 6Gbps • Supported M.2 SSD Size: 2230, 2242, 2260, 2280 Important Note • M Key M.2 slot is only for use with NVMe M.2 SSD, B Key M.2 slot is only for use with SATA M.2 SSD • SATA M.2 SSD on B Key slot requires a SATA 7-pin data cable connection to the motherboard for proper operation Package Contents • 1x PCIe Expansion Card • 1x Low profile bracket • 1x SATA Cable • Screws Set

Brand: ASUS

Category: Motherboards / Accessories

SKU: HYPER M.2 X16 GEN 5 CARD

Description: ASUS Hyper M.2 x16 Gen5 Card (PCIe 5.0/4.0) supports up to four NVMe M.2 (2242/2260/2280/22110) devices at up to 512 Gbps for RAID functions across diverse CPU platforms •1 x 6-pin PCIe power connector and two-phase power solution with up to 14-watt output to support the latest NVMe drives •Large heatsink and active fan reduces M.2 SSD temperatures for unthrottled transfer speeds and enhanced reliability; additional fan cable connects to the motherboard's chassis fan header to allow the motherboard to control and regulate fan speed •Adapted server-grade PCB supports up to four PCIe 5.0/4.0 M.2 drives, with up to 512 Gbps bandwidth for smooth data transfers SPECIFICATION Model Hyper M.2 x16 Gen5 Card Spec PCIe 5.0 x16 interface, support data transfer rates up to 512 Gbps. 4 x M.2 slots (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0)* * Supports PCIe M.2 storage devices only. 1 x M.2 FAN Power Switch 4 x M.2 access LEDs Active fan with heatsink, support fan control from MB chassis fan header Dimensions 29 (L)*12.2(W) *1.5(H)cm

Brand: Gigabyte

Category: Motherboards / Accessories

SKU: GC-TPM2.0 SPI V2 1.0

Description: Gigabyte GC-TPM2.0 SPI 2.0 Module with SPI interface (Exclusive for Intel 400-series), Intel 400 series/Z390 M GAMING, AMD 550 series (LS) Compute Securely with GIGABYTE's TPM 2.0 Solution These days security is on the forefront of everyone's mind. With cyber criminals around the world actively trying to steal your financial and personal information, you need to do everything you can to protect yourself. While many users protect themselves with anti-virus programs and other software measures, the reality is if you want complete peace of mind you’ll need to take things a step further and use a hardware based security solution. This is especially critical for employees such as accountants or insurance agent where they handle personal information of many individuals. Thankfully there is a solution to help keep your precious data secure: a Trusted Platform Module (TPM). Adding another layer of security The TPM is a discrete cryptographic processor attached to a daughter board which plugs into the motherboard. The TPM securely stores your cryptographic key which can be created with encryption software such as Windows BitLocker. Without this key, the contents of the user's PC will remain encrypted and safe from unauthorized access. This means that when using a TPM, the data on our PC will be safe not only from external software threats, but also physical theft. The GIGABYTE TPM GC-TPM2.0 SPI 2.0 features the SLB9670, an advanced 2048-bit cryptographic processor by Infineon®. The SLB9670 by Infineon processor meets all the latest industry standards including TPM 2.0 as well as Common Criteria (EAL4+). This processor creates a military-grade encryption key that allows the use to encrypt your hard drive with Windows BitLocker, and also verify your identity online for tasks like online banking. The GC-TPM2.0 SPI 2.0 is compatible with GIGABYTE motherboards of that include a TPM header on below: Intel platform: Intel 400 series / Z390 M GAMING AMD platform: AMD 550 series / GA-AB350M-DASH Gigabyte GC-TPM2.0 SPI 2.0 Controller SLB9670 FW7.63 Interface SPI bus
