Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: C32SP-10NP

Description: PANORAMA 10m CS32 CABLE ASSEMBLY SMA(m) - N(m)

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: BSM-6-60-5SP

Description: PANORAMA 2×2 MiMo 4G/5G MIMO OMNI TUBE ANTENNA 5m SMA(m), Wall, rail, or mast mount, Band71 Ready The BS[G]M-6-60 antenna is a MiMo Omni-directional broadband antenna range for 4G/5G devices. It covers 617-960/1427-6000MHz and is suitable for external or internal installation. The mounting bracket enables simple wall mounting using the supplied screws and wall plugs and mast/rail mounting using the supplied clamps. The omni-directional radiation pattern allows easy placement of the antennas in an elevated position, without requiring directional alignment. The BSGM type is supplied with an integrated GPS/GNSS module with 26dB LNA gain and advanced filtering to combat noise. This antenna is an ideal solution for loT use in industrial and domestic environments for cellular modems/routers and Machine to Machine (M2M) wireless connectivity applications. The weather and corrosion-resistant design also make the antenna suitable for certain marine and costal applications. Cradlepoint Approved for E100/E102 Series ELECTRICAL DATA Pattern Omnidirectional Max Input Power(W) 10 Frequency Range | Gain 617 – 960MHz | 3dBi; 1427 – 2700MHz | 6dBi; 3400 – 4200MHz | 5dBi; 4900 – 6000MHz | 5dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements No UHF Elements No GPS DATA GPS Frequency Range 1559-1612MHz LNA GAIN (dB) 26 Number of GPS Elements No; 1 Module MECHANICAL DATA Colour White Height 540 (mm) | 21.26 (in) Diameter 86 (mm) | 3.39 (in) Operating Temperature -40°/ +85°C (-40.0°/ +185.0°F) CABLE DATA Cable Length – LTE min: 0.5 (m) | 1.64 (ft); max: 5 (m) | 16.4 (ft) Cable length – GPS min: 0.5 (m) | 1.64 (ft); max: 5 (m) | 16.4 (ft) Cable Type (LTE) FR CS32 Cable Type (GPS) FR CS29 TERMINATION DATA Connector (GPS) FAKRA C; N (m); SMA (m); N (f) Connector (LTE) N (f); FAKRA D; N (m); SMA (m); FAKRA C MOUNTING DATA Mounting Type Fixed Mast; Panel; Wall Mounting Methods Mast; Panel; Wall APPROVALS DATA IP Rating IP67

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: SHKG-6-60

Description: PANORAMA 2×2 MiMo Cellular Sharkee Antenna Black – 617-960 / 1710-6000MHz, 4G/5G, GPS/GNSS with advanced filtering for LTE Band 13/14 4G/5G MiMo Antenna Discrete OEM Style Sharkfin. The SHKG ‘Sharkee®’ range has become a byword for industry leading technology in discrete OEM sharkfin housing. The SHKG-6- 60 brings 5G capability to the product family. The antenna can be fitted on a metallic or non-metallic panel and still offer similar performance. The SHKG shark fin style design provides multiple antenna functions while remaining discreet and is suitable for public safety (overt/covert), industrial and transport applications where a cost effective, efficient, and robust antenna is essential. Requiring only a single hole mounting, the SHKG reduces vehicle damage, installation time & cost, and visual impact whilst protecting a vehicle’s resale value. Pattern Omnidirectional Max Input Power(W) 10 Frequency Range | Gain 617 – 960MHz | 5dBi; 1710 – 3800MHz | 8dBi; 4900 – 6000MHz | 9dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements No; 2 x 2 MIMO; 3 x 3 MIMO; 4 x 4 MIMO UHF Elements No GPS Frequency Range 1562-1612MHz LNA GAIN (dB) 26 Number of GPS Elements 1 Module Cable Length – LTE min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable length – GPS min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Length – WIFI min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Type (LTE) FR RG174 Cable Type (GPS) FR RG174 Cable Type (WIFI) FR RG174 Quantity of Cell Cable 2 Quantity of GPS/GNSS Extension 1 Quantity of WIFI Extension max: 4 Connector (WIFI) Reverse Polarity SMA; SMA (f) Connector (GPS) SMA (m); FME (f) Connector (LTE) SMA (m) Mounting Type Fixed Panel Mounting Type Temp Magnetic Mounting Methods Magnetic; Panel IP Rating IP69K Cable Flammability EN45545-2 HL3; UN ECE R118; EN6722 Technology GPS; 4G/5G; 5G; 2G/3G; 2G/3G/4G; Band 71 600MHz ready; FirstNet; GNSS; WIFI MIMO; WIFI

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: WMM8G-7-38-5SP

Description: PANORAMA 2×2 MiMo Wideband Cellular LTE antenna, 9dBi, Wall or Mast mounted700-3800MHz for 2G/3G/4G/5G LTE IP65 rated housing The WMM8G-7-38 antenna is a high gain directional 2×2 MIMO signal boosting antenna for 4G/5G LTE. Incorporating two separately fed wideband elements in a single housing the WMM8G is equipped to provide client-side MIMO and diversity support for 4G/5G LTE. The rugged, weatherproof housing is designed for wall mounting. Wall and mast mounting brackets are provided. 5 metres of fitted low loss double shielded twin cable minimizes exposed connector joints and simplifies cable management for easy installation. The WMM8G-7-38-5SP and WMM8G-7-38-03NJ are upgraded versions of the popular WMM8G-7-27-5SP and WMM8G-7-27-03NJ antennas covering the new 3.4-3.8GHz frequency bands. Cradlepoint Approved for S700, IBR600, E100/ E102 Series Pattern Directional Max Input Power(W) 20 Frequency Range | Gain 698 – 960MHz | 6dBi; 1710 – 2170MHz | 9dBi; 2396 – 2700MHz | 9dBi; 3400 – 3800MHz | 9dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements No UHF Elements No Number of GPS Elements No Colour White Operating Temperature -45°/ +80°C (-49.0°/ +176.0°F) Cable Length – LTE min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Type (LTE) CS29 Connector (LTE) N (f); SMA (m) Mounting Type Fixed Desk; Mast; Wall Mounting Methods Desk; Mast; Wall IP Rating IP65 Cable Flammability EN45545-2 HL3; UN ECE R118; EN6722 Technology 4G/5G; 5G; 2G/3G; 2G/3G/4G

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LP-IN2455

Description: PANORAMA 2-in-1 4G/5G DOME Antenna Black 5m FTD CABLS ‘Great White’ | 2×2 MiMo 4G/5G, IK10, IP69K The L[G]M[X]M[X]-6-60[-24-58] range has been designed to provide 2×2 4G/5G MiMo performance from 617-960/1427-6000MHz in a robust low profile package.The flexible platform allows the main elements to be combined with a number of other functions including GPS/GNSS and up to 6×6 MiMo WiFi 2.4/4.9-7.2GHz.The antenna is designed to be panel mounted and can be fitted on a conductive or non-conductive panel. Supplied with integrated flame retardant RG174 cables (Compliant to UN ECE R118.03 and EN45545-2) and a halogen-free flame retardant radome the antenna is suitable for many environments and applications.The LGM variants have an integrated GPS/GNSS module supporting GPS, Glonass, Galileo and Compass with 26dB LNA gain. This GPS module features advanced filtering for LTE B13/14 designed to minimise potential in-band interference.The antenna is available with a black or white radome which meets IK10 for vandal resistance and IP69K for ingress protection. Pattern Omnidirectional Max Input Power(W) 20 Frequency Range | Gain 617 – 960MHz | 5dBi; 1710 – 3800MHz | 9dBi; 4900 – 6000MHz | 10dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements 6 x 6 MIMO; No; 2 x 2 MIMO; 4 x 4 MIMO; 3 x 3 MIMO UHF Elements No GPS Frequency Range 1562-1612MHz LNA GAIN (dB) 26 Number of GPS Elements 1 Module; No Cable Length – LTE min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable length – GPS min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Length – WIFI min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Type (LTE) FR RG174 Cable Type (GPS) FR RG174 Cable Type (WIFI) FR RG174 Quantity of Cell Cable 2 Quantity of GPS/GNSS Extension 1 Quantity of WIFI Extension max: 6 Connector (WIFI) Reverse Polarity SMA; SMA (f) Connector (GPS) SMA (m); FME (f) Connector (LTE) SMA (m) MOUNTING DATA Mounting Type Fixed Panel Mounting Type Temp Magnetic Mounting Methods Panel

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LP-IN2455-W

Description: PANORAMA 2-in-1 4G/5G DOME Antenna White 5m FTD CABLS ‘Great White’ | 2×2 MiMo 4G/5G, 617-960/1427-6 The L[G]M[X]M[X]-6-60[-24-58] range has been designed to provide 2x2 4G/5G MiMo performance from 617-960/1427-6000MHz in a robust low profile package. The flexible platform allows the main elements to be combined with a number of other functions including GPS/GNSS and up to 6x6 MiMo WiFi 2.4/4.9-7.2GHz.The antenna is designed to be panel mounted and can be fitted on a conductive or non-conductive panel. Supplied with integrated flame retardant RG174 cables (Compliant to UN ECE R118.03 and EN45545-2) and a halogen-free flame retardant radome the antenna is suitable for many environments and applications.The LGM variants have an integrated GPS/GNSS module supporting GPS, Glonass, Galileo and Compass with 26dB LNA gain. This GPS module features advanced filtering for LTE B13/14 designed to minimise potential in-band interference. Pattern Omnidirectional Max Input Power(W) 20 Frequency Range | Gain 617 – 960MHz | 5dBi; 1710 – 3800MHz | 9dBi; 4900 – 6000MHz | 10dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements 6 x 6 MIMO; No; 2 x 2 MIMO; 4 x 4 MIMO; 3 x 3 MIMO UHF Elements No GPS Frequency Range 1562-1612MHz LNA GAIN (dB) 26 Number of GPS Elements 1 Module; No Cable Length – LTE min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable length – GPS min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Length – WIFI min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Type (LTE) FR RG174 Cable Type (GPS) FR RG174 Cable Type (WIFI) FR RG174 Quantity of Cell Cable 2 Quantity of GPS/GNSS Extension 1 Quantity of WIFI Extension max: 6 Connector (WIFI) Reverse Polarity SMA; SMA (f) Connector (GPS) SMA (m); FME (f) Connector (LTE) SMA (m) MOUNTING DATA Mounting Type Fixed Panel Mounting Type Temp Magnetic Mounting Methods Panel;Magnetic IP Rating IP69K Cable Flammability EN45545-2 HL3; UN ECE R118; EN6722 Technology GPS; WIFI MIMO; 4G/5G; WIFI; 5G

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: C32NP-2SMARV

Description: PANORAMA 2m CS32 CABLE N(m) - SMA(m) RP

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: DMM-6-60-2SP

Description: PANORAMA 2x2 Mount MiMo Portable Antenna 4G/5G Desk, Window or Wall Mount Antenna, 617-960 / 1710-6000MHz, SMA (m), Band71 Ready The DMM portable antenna is an innovative antenna design which provides 2×2 MiMo function for 4G/5G with fallback to 3G/2G.Incorporating two separately fed, ultra wideband elements in a single housing, the DMM is equipped to provide portable MiMo and diversity function for frequencies from 617-960/1710-6000MHz to cover global LTE and 5G sub mmWave bands. A handy suction window mount enables users to optimise their signal by antenna position, with instant installation and easy removal. For more permanent use, screw and adhesive pad mounting options are also provided. The antenna is supplied with 2 metres (6’) of twinned coaxial cable with the option of SMA or TS9 plug connectors.The DMM is a cost effective, value added product for network operators and service providers, helping to provide a stable connection with improved data rates for subscribers, thereby improving satisfaction and retention. Cradlepoint Approved for S700, IBR600C, E100/E102 Series The ideal loT antenna Multiple mounting options Integrated coax with connector terminations ELECTRICAL DATA Pattern Omnidirectional Max Input Power(W) 20 Frequency Range | Gain 617 – 960MHz | 3dBi; 1427 – 2700MHz | 5dBi; 3400 – 6000MHz | 6dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements No UHF Elements No GPS DATA Number of GPS Elements No MECHANICAL DATA Colour Black Length 16 (mm) | 0.63 (in) Width 184.6 (mm) | 7.27 (in) Height 176.3 (mm) | 6.94 (in) Operating Temperature -40°/ +80°C (-40.0°/ +176.0°F) CABLE DATA Cable Length – LTE min: 0.5 (m) | 1.64 (ft); max: 2 (m) | 6.56 (ft) Cable Type (LTE) RG174 TERMINATION DATA Connector (LTE) SMA (m); TS9 (m) MOUNTING DATA Mounting Type Fixed Desk Mounting Type Temp Glass Mount Mounting Methods Desk; Glass Mount TECHNOLOGY DATA Technology 4G/5G; 5G; 2G/3G; 2G/3G

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LGAM-7-27-24-58

Description: PANORAMA 2x2 Multifunction MiMo Antenna 4G/5G LTE 698-3800MHz 2x2 MiMo WiFi 2.4/5.0GHz Low profile fin design This high-performance antenna offers multiple antenna functions for applications where a cost-effective, efficient and robust antenna is essential. It is ideal for vending machines, payment terminals and other M2M applications. The L[G]AM consists of a 2×2 MiMo function for 2G/3G/4G/5G covering 698-3800MHz, a 2×2 MiMo function for 2.4/5GHz WiFi and an optional active antenna for GPS/GLONASS/Galileo/BeiDou with 26dB gain LNA for high-quality positioning and filtering. The antenna maintains a high level of performance even when mounted on a non-metallic surface. Cradlepoint Approved for S700, IBR600 Series Compact low profile MiMo LTE antenna 1x or 2×2 MiMo dual-band WiFi Optional GNSS version available High performance in a distinctive design Covers all 2G/3G/4G/5G LTE cellular band Dual-band 2.4/5GHz WiFi Weatherproof IP66 Certified design Single hole mount with a small footprint Static M2M & loT devices Remote monitoring Smart metering Vending machines ELECTRICAL DATA Pattern Omnidirectional Max Input Power(W) 25 Frequency Range | Gain 698 – 960MHz | 2dBi; 1710 – 3800MHz | 5dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements 2 x 2 MIMO; No UHF Elements No GPS DATA GPS Frequency Range 1562-1612MHz LNA GAIN (dB) 26 Number of GPS Elements 1 Module; No MECHANICAL DATA Colour Black Operating Temperature -40°/ +80°C (-40.0°/ +176.0°F) CABLE DATA Cable Length – LTE 3 (m) | 9.84 (ft) Cable length – GPS 3 (m) | 9.84 (ft) Cable Length – WIFI 3 (m) | 9.84 (ft) Cable Type (LTE) RG174 Cable Type (GPS) RG174 Cable Type (WIFI) RG174 TERMINATION DATA Connector (WIFI) SMA Rev Pol; FAKRA I Connector (GPS) SMA (m); FAKRA C Connector (LTE) SMA (m); FAKRA D MOUNTING DATA Mounting Type Fixed Panel Mounting Methods Panel APPROVALS DATA IP Rating IP66 TECHNOLOGY DATA Technology GPS; WIFI MIMO; 4G/5G; WIFI; 5G; 2G/3G; 2G/3

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: DWMM4-6-60-5SP

Description: PANORAMA 4×4 MiMo Omnidirectional Antenna, 4G/5G LTE Ready, WALL, DESK, MOUNT, 617-6000MHz, 5m SMA(m), IP66 rated The DWMM4[G]-6-60 Antenna Provides a 4x4 MiMo Solution for Global 4G/5G Networks from 617-6000MHz. Incorporating four separately fed ultra wideband elements in a single housing the DWMM4[G] is suitable for a huge range of fixed site and failover applications. The supplied mounting bracket enables simple wall mounting using the supplied screws and wall plugs and mast mounting using the supplied clamps. The antenna can also be mounted with screws directly to non-conductive panels or internal walls or stood on a desk using supplied mounting feet. The omnidirectional radiation pattern allows easy placement of the antenna without requiring directional alignment. The DWMM4G type is supplied with an integrated GPS/GNSS module with 26dB LNA gain and advanced filtering to combat noise. The antenna is fitted with an integrated flame retardant CS32 cable (FR CS29 for GPS/GNSS) which minimises exposed connector joints and simplifies cable management for easy installation. Suitable for Indoor or Outdoor Use Branch Office & Enterprise Failover ELECTRICAL DATA Max Input Power(W) 10 Cellular LTE Elements 4 x 4 MIMO WIFI Elements No UHF Elements No GPS DATA LNA GAIN (dB) 26 Number of GPS Elements No; 1 Module MECHANICAL DATA Colour White Length 371 (mm) | 14.61 (in) Width 40 (mm) | 1.57 (in) Height 221 (mm) | 8.70 (in) Operating Temperature -40°/ +80°C (-40.0°/ +176.0°F) TERMINATION DATA Connector (GPS) SMA (m); FAKRA C; N (m); N (f) Connector (LTE) SMA (m); N (f); FAKRA D; N (m) MOUNTING DATA Mounting Type Fixed Desk; Mast; Wall Mounting Methods Desk; Mast; Wall; Pole APPROVALS DATA IP Rating IP66 TECHNOLOGY DATA Technology 4G/5G; 5G; 2G/3G; 2G/3G/4G; Band 71 600MHz ready; GPS; GNSS

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: EF-6-60-3SP

Description: PANORAMA 4G/5G EASYFIT ADHESIVE ANTENNA 3m SMA PLUG

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: DMM4-6-60-2SP

Description: PANORAMA 4x4 MiMo 4G/5G Desk Mount MiMo Antenna – Portable Antenna, Window or Wall Mount Antenna, 617-960 / 1710-6000MHz, SMA (m), Band71 Ready The DMM4 portable antenna is an innovative antenna design which provides 4×4 MiMo function for 4G/5G with fallback to 3G/2G. The DMM4 antenna is a future proof solution for Cat 18/20 4G and 5G devices. Incorporating four separately fed, ultra wide band elements for 617-960/1710- 6000MHz in a single housing, the DMM4 provides a 4×4 MiMo function. It can also provide 2x 2×2 MiMo function for a router with dual modems, each requiring a 2×2 antenna system. The DMM4 is highly portable and features desk mount feet which fold out for use, and flat for transport. A suction window mount enables the user to optimise their signal in multiple locations, with instant installation and easy removal. For more permanent use, screw and adhesive pad mounting options are also provided. The antenna is supplied with two twinned 2m (6’) length coaxial cables, with the option of SMA, TS9 or FAKRA D connectors. The DMM4 is a cost eff ective value added product for network operators and service providers ensuring a stable link with improved data rates for subscribers, thereby improving satisfaction and retention. ELECTRICAL DATA Pattern Omnidirectional Max Input Power(W) 2 Typical VSWR 2.5:1 Frequency Range | Gain 617 – 960MHz | 2dBi; 1427 – 2700MHz | 4dBi; 2700 – 6000MHz | 5dBi Cellular LTE Elements 4 x 4 MIMO WIFI Elements No UHF Elements No GPS DATA Number of GPS Elements No MECHANICAL DATA Colour Black Length 23 (mm) | 0.91 (in) Width max: 185 (mm) | 7.28 (in) Height max: 185 (mm) | 7.28 (in) Operating Temperature -40°/ +80°C (-40.0°/ +176.0°F) CABLE DATA Cable Length – LTE 2 (m) | 6.56 (ft) Cable Type (LTE) RG174 TERMINATION DATA Connector (LTE) SMA (m); FAKRA D; TS9 (m) MOUNTING DATA Mounting Type Fixed Desk; Wall Mounting Type Temp Hook/Loop or Adhesive Mounting Methods Desk; Hook/Loop or Adhesive; Wall TECHNOLOGY DATA Technology 4G/5G; 5G; CBRS; 2G/3G/4G; Band 71 600MHz ready

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LG-IN2445-W-LC

Description: PANORAMA 7-in-1 5G DOME Antenna White, 4×4 MiMo 4G/5G, up to 6×6 MiMo WiFi, optional GPS/GNSS Vehicle Ant,SMA (m) 617-960/1710-6000MHz, IK10, IP69K(loose 5m cables) The MAKO® 5G Dome is a range of high-performance 4×4 MiMo antennas covering 617-960/1710-6000MHz with optional GPS/GNSS and optional 2×2, 3×3 or 4×4, or 6×6 MiMo/Diversity at 2.4/5.0/7.2GHz. The MAKO® 5G Dome consists of up to 11 elements; four isolated high-performance antenna elements covering 617-960/1710-6000MHz offer MiMo/Diversity at cellular/LTE frequencies, up to 6 optional dual band elements covering 2.4 & 5.0/7.2GHz support MiMo/Diversity operation for WiFi and optional high-performance GPS/GNSS antenna with an integrated 26dB gain LNA and high-quality filtering offers unparalleled positioning accuracy. None of the antennas in this range require a metallic ground plane, and all maintain a high level of performance even when mounted on non-metallic surfaces. Designed for latest generation LTE Cat 18/20 routers and devices Low profile antenna with up to 11 functions in 1 4×4 MiMo 4G/5G LTE cellular, Optional GPS/GNSS & optional MiMo 2.4/7.2GHz in one housing Kits with extension cables available for a range of LTE routers Flame retardant cables compliant to UNECE R118 Pre-terminated antenna connectors fitted as standard Cable flags attached for easy cable identification and installation Extension cable available upon request Single Hole Panel Mount Installation Suitable for FirstNet (USA) and ESN (UK) Public Safety Networks Ground Plane Independent | Suitable for Conductive or Non-Conductive Surfaces ELECTRICAL DATA Pattern Omnidirectional Max Input Power(W) 10 Frequency Range | Gain 617 – 960MHz | 4dBi; 1710 – 3800MHz | 8dBi; 4900 – 6000MHz | 9dBi Cellular LTE Elements 4 x 4 MIMO WIFI Elements No; 2 x 2 MIMO; 4 x 4 MIMO; 6 x 6 MIMO; 5 x 5 MIMO; 3 x 3 MIMO UHF Elements No GPS DATA GPS Frequency Range 1562-1612MHz LNA GAIN (dB) 26 Number of GPS Elements 1 Module; No MECHANICAL DATA Colour Black; White Height 80 (mm) | 3.15 (in) Diameter 180 (mm) | 7.09 (in) Operating Temperature -40°/ +80°C (-40.0°/ +176.0°F) CABLE DATA Cable Length – LTE min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable length – GPS min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Length – WIFI min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Type (LTE) FR RG174; RG174 Cable Type (GPS) FR RG174 Cable Type (WIFI) FR RG174; RG174 Quantity of Cell Cable 4 Quantity of GPS/GNSS Extension 1 Quantity of WIFI Extension max: 6 TERMINATION DATA Connector (WIFI) Reverse Polarity SMA; FAKRA I; SMA (f) Connector (GPS) SMA (m); FAKRA C; FME (f) Connector (LTE) SMA (m); FAKRA D; N (f) MOUNTING DATA Mounting Type Fixed Panel Mounting Type Temp Magnetic Mounting Methods Magnetic; Panel APPROVALS DATA IP Rating IK10; IP69K Cable Flammability EN45545-2 HL3; UN ECE R118; EN6722 TECHNOLOGY DATA Technology GPS; 4G/5G; 5G; 2G/3G; 2G/3G/4G; Band 71 600MHz ready; FirstNet; GNSS; WIFI MIMO; WIFI LG-IN2445-W-LC White 4 x 4 MIMO 1 Module 2 x 2 MIMO 5m 5m 5m SMA (m) SMA (m) Reverse Polarity SMA Cables Loose Cables Loose Cables Loose

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LG-IN2445

Description: PANORAMA 7 -in-1 5G DOME Antenna Black, 4×4 MiMo 4G/5G, up to 6×6 MiMo WiFi, optional GPS/GNSS Vehicle Ant,SMA (m) 617-960/1710-6000MHz, IK10, IP69K (cables fitted -5m) The MAKO® 5G Dome is a range of high-performance 4×4 MiMo antennas covering 617-960/1710-6000MHz with optional GPS/GNSS and optional 2×2, 3×3 or 4×4, or 6×6 MiMo/Diversity at 2.4/5.0/7.2GHz. The MAKO® 5G Dome consists of up to 11 elements; four isolated high-performance antenna elements covering 617-960/1710-6000MHz offer MiMo/Diversity at cellular/LTE frequencies, up to 6 optional dual band elements covering 2.4 & 5.0/7.2GHz support MiMo/Diversity operation for WiFi and optional high-performance GPS/GNSS antenna with an integrated 26dB gain LNA and high-quality filtering offers unparalleled positioning accuracy. None of the antennas in this range require a metallic ground plane, and all maintain a high level of performance even when mounted on non-metallic surfaces. Designed for latest generation LTE Cat 18/20 routers and devices Low profile antenna with up to 11 functions in 1 4×4 MiMo 4G/5G LTE cellular, Optional GPS/GNSS & optional MiMo 2.4/7.2GHz in one housing Kits with extension cables available for a range of LTE routers Flame retardant cables compliant to UNECE R118 Pre-terminated antenna connectors fitted as standard Cable flags attached for easy cable identification and installation Extension cable available upon request Available in Black or White Single Hole Panel Mount Installation Suitable for FirstNet (USA) and ESN (UK) Public Safety Networks Ground Plane Independent | Suitable for Conductive or Non-Conductive Surfaces ELECTRICAL DATA Pattern Omnidirectional Max Input Power(W) 10 Frequency Range | Gain 617 – 960MHz | 4dBi; 1710 – 3800MHz | 8dBi; 4900 – 6000MHz | 9dBi Cellular LTE Elements 4 x 4 MIMO WIFI Elements No; 2 x 2 MIMO; 4 x 4 MIMO; 6 x 6 MIMO; 5 x 5 MIMO; 3 x 3 MIMO UHF Elements No GPS DATA GPS Frequency Range 1562-1612MHz LNA GAIN (dB) 26 Number of GPS Elements 1 Module; No MECHANICAL DATA Colour Black; White Height 80 (mm) | 3.15 (in) Diameter 180 (mm) | 7.09 (in) Operating Temperature -40°/ +80°C (-40.0°/ +176.0°F) CABLE DATA Cable Length – LTE min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable length – GPS min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Length – WIFI min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Type (LTE) FR RG174; RG174 Cable Type (GPS) FR RG174 Cable Type (WIFI) FR RG174; RG174 Quantity of Cell Cable 4 Quantity of GPS/GNSS Extension 1 Quantity of WIFI Extension max: 6 TERMINATION DATA Connector (WIFI) Reverse Polarity SMA; FAKRA I; SMA (f) Connector (GPS) SMA (m); FAKRA C; FME (f) Connector (LTE) SMA (m); FAKRA D; N (f) MOUNTING DATA Mounting Type Fixed Panel Mounting Type Temp Magnetic Mounting Methods Magnetic; Panel APPROVALS DATA IP Rating IK10; IP69K Cable Flammability EN45545-2 HL3; UN ECE R118; EN6722 TECHNOLOGY DATA Technology GPS; 4G/5G; 5G; 2G/3G; 2G/3G/4G; Band 71 600MHz ready; FirstNet; GNSS; WIFI MIMO; WIFI LG-IN2445 Black 4 x 4 MIMO 1 Module 2 x 2 MIMO 5m 5m 5m SMA (m) SMA (m) Reverse Polarity SMA Cables Fitted Cables Fitted Cables Fitted

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LG-IN2448

Description: PANORAMA 9-in-1 4G/5G DOME Antenna Black 5m FTD CABLS ‘Great White’ | 2×2 MiMo 4G/5G,SMA (m) 617-960/1427-6000MHz, IK10, IP69K The L[G]M[X]M[X]-6-60[-24-58] range has been designed to provide 2×2 4G/5G MiMo performance from 617-960/1427-6000MHz in a robust low profile package.The flexible platform allows the main elements to be combined with a number of other functions including GPS/GNSS and up to 6×6 MiMo WiFi 2.4/4.9-7.2GHz.The antenna is designed to be panel mounted and can be fitted on a conductive or non-conductive panel. Supplied with integrated flame retardant RG174 cables (Compliant to UN ECE R118.03 and EN45545-2) and a halogen-free flame retardant radome the antenna is suitable for many environments and applications.The LGM variants have an integrated GPS/GNSS module supporting GPS, Glonass, Galileo and Compass with 26dB LNA gain. This GPS module features advanced filtering for LTE B13/14 designed to minimise potential in-band interference. Pattern Omnidirectional Max Input Power(W) 20 Frequency Range | Gain 617 – 960MHz | 5dBi; 1710 – 3800MHz | 9dBi; 4900 – 6000MHz | 10dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements 6 x 6 MIMO; No; 2 x 2 MIMO; 4 x 4 MIMO; 3 x 3 MIMO UHF Elements No GPS Frequency Range 1562-1612MHz LNA GAIN (dB) 26 Number of GPS Elements 1 Module; No Cable Length – LTE min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable length – GPS min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Length – WIFI min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Type (LTE) FR RG174 Cable Type (GPS) FR RG174 Cable Type (WIFI) FR RG174 Quantity of Cell Cable 2 Quantity of GPS/GNSS Extension 1 Quantity of WIFI Extension max: 6 Connector (WIFI) Reverse Polarity SMA; SMA (f) Connector (GPS) SMA (m); FME (f) Connector (LTE) SMA (m) MOUNTING DATA Mounting Type Fixed Panel Mounting Type Temp Magnetic Mounting Methods Panel

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LG-IN2448-W

Description: PANORAMA 9-in-1 4G/5G DOME Antenna White 5m FTD CABLS ‘Great White’ | 2×2 MiMo 4G/5G,SMA (m) 617-960/1427-6000MHz, IK10, IP69K The L[G]M[X]M[X]-6-60[-24-58] range has been designed to provide 2×2 4G/5G MiMo performance from 617-960/1427-6000MHz in a robust low profile package.The flexible platform allows the main elements to be combined with a number of other functions including GPS/GNSS and up to 6×6 MiMo WiFi 2.4/4.9-7.2GHz.The antenna is designed to be panel mounted and can be fitted on a conductive or non-conductive panel. Supplied with integrated flame retardant RG174 cables (Compliant to UN ECE R118.03 and EN45545-2) and a halogen-free flame retardant radome the antenna is suitable for many environments and applications.The LGM variants have an integrated GPS/GNSS module supporting GPS, Glonass, Galileo and Compass with 26dB LNA gain. This GPS module features advanced filtering for LTE B13/14 designed to minimise potential in-band interference. Pattern Omnidirectional Max Input Power(W) 20 Frequency Range | Gain 617 – 960MHz | 5dBi; 1710 – 3800MHz | 9dBi; 4900 – 6000MHz | 10dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements 6 x 6 MIMO; No; 2 x 2 MIMO; 4 x 4 MIMO; 3 x 3 MIMO UHF Elements No GPS Frequency Range 1562-1612MHz LNA GAIN (dB) 26 Number of GPS Elements 1 Module; No Cable Length – LTE min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable length – GPS min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Length – WIFI min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Type (LTE) FR RG174 Cable Type (GPS) FR RG174 Cable Type (WIFI) FR RG174 Quantity of Cell Cable 2 Quantity of GPS/GNSS Extension 1 Quantity of WIFI Extension max: 6 Connector (WIFI) Reverse Polarity SMA; SMA (f) Connector (GPS) SMA (m); FME (f) Connector (LTE) SMA (m) MOUNTING DATA Mounting Type Fixed Panel Mounting Type Temp Magnetic Mounting Methods Panel

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: B4BE-6-60-5SP

Description: PANORAMA BRACKET MOUNT ANTENNA 617-960/1710-6000MHz 5m SMA(m) Wall, Mast or Panel Mount, 4G/5G LTE Covering 600-6000MHz The Panorama B4BE is a robust bracket mount antenna for LTE, M2M, and IoT applications. The B4BE range has been designed to provide cost-effective coverage booster antennas for 2G/3G/4G and 5G devices. The antennas are designed for wall or mast mounting and are weatherproof which allows the device to reap the benefits of an antenna mounted in an elevated or external location where the signal is strongest. The Omni-directional radiation pattern allows the antenna to be quickly installed while the global Cellular/GSM/LTE coverage provided by the antenna allows it to be utilised for 2G/3G & 4G applications the world over. Integrated Low Loss Cable 5dBi Peak Gain Performance UV Stable & IP Rated ELECTRICAL DATA Pattern Omnidirectional Max Input Power(W) 30 Frequency Range | Gain 617 – 960MHz | 2dBi; 1710 – 2700MHz | 3.5dBi; 3400 – 3800MHz | 5dBi Operating Temperature -40°/ +80°C (-40.0°/ +176.0°F); -40°/ +85°C (-40.0°/ +185.0°F) Cellular LTE Elements SiSo WIFI Elements No UHF Elements No GPS DATA Number of GPS Elements No Cable Type (LTE) CS29 Connector (LTE) SMA (m) IP Rating IP66 Material Flammability UL746C F2, UL 94-HB Technology 4G/5G; 5G; 2G/3G; 2G/3G/4G; Band 71 600MHz ready

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: C240N-15SP

Description: Panorama Antennas’ CS240 cable is designed for cellular and WiFi applications that require a long run of cable. This 6mm (0.24') cable offers unparalleled attenuation performance while maintaining some flexibility, making it suitable for a wide range of fixed and mobile applications. This is the 15m version and is perfectly suited to the WMM8G-7-38-03J Antenna. Mechanical Data Available Colours Black Jacket Material Polyethene Diameter (mm) 6.1 Connector SMA (m); N (m)

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LPAMM-7-27-24-58-1

Description: PANORAMA Compact Low Profile Magnetic Antenna, 2×2 MiMo 4G/5G Ready Covering 700-3800MHz WIFI 1m SP, Weatherproof IP66 This high-performance antenna offers multiple antenna functions for applications where a cost-effective, efficient and robust antenna is essential. It is ideal for vending machines, payment terminals and other M2M applications where installation without drilling a hole is desired. The L[G]AM consists of 2×2 MiMo function for 2G/3G/4G/5G covering 698-3800MHz, 2×2 MiMo function for 2.4/5GHz WiFi and an optional active antenna for GPS/GLONASS/Galileo/BeiDou with 26dB gain LNA for high-quality positioning and filtering. The antenna maintains a high level of performance even when mounted on a non-metallic surface. The antenna is designed to be mounted magnetically. Pattern Omnidirectional Max Input Power(W) 25 Frequency Range | Gain 698 – 960MHz | 2dBi; 1710 – 3800MHz | 5dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements 2 x 2 MIMO; No UHF Elements No GPS Frequency Range 1562-1612MHz LNA GAIN (dB) 26 Number of GPS Elements 1 Module; No Cable Length – LTE min: 1 (m) | 3.28 (ft); max: 3 (m) | 9.84 (ft) Cable length – GPS min: 1 (m) | 3.28 (ft); max: 3 (m) | 9.84 (ft) Cable Length – WIFI min: 1 (m) | 3.28 (ft); max: 3 (m) | 9.84 (ft) Cable Type (LTE) RG174 Cable Type (GPS) RG174 Cable Type (WIFI) RG174 Connector (WIFI) SMA Rev Pol Connector (GPS) SMA (m) Connector (LTE) SMA (m) Mounting Type Temp Magnetic Mounting Methods Magnetic IP Rating IP66 Technology GPS; WIFI MIMO; 4G/5G; WIFI; 5G; 2G/3G; 2G/3G/4G; GNSS; WIFI SISO

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LGAMM-7-27-24-58-1

Description: PANORAMA Compact Low Profile Magnetic Antenna, 2×2 MiMo 4G/5G Ready Covering 700-3800MHz WIFI 1m SP, Weatherproof IP66 Dual Band WiFi & Optional GPS/G This high-performance antenna offers multiple antenna functions for applications where a cost-effective, efficient and robust antenna is essential. It is ideal for vending machines, payment terminals and other M2M applications where installation without drilling a hole is desired. The L[G]AM consists of 2×2 MiMo function for 2G/3G/4G/5G covering 698-3800MHz, 2×2 MiMo function for 2.4/5GHz WiFi and an optional active antenna for GPS/GLONASS/Galileo/BeiDou with 26dB gain LNA for high-quality positioning and filtering. The antenna maintains a high level of performance even when mounted on a non-metallic surface. The antenna is designed to be mounted magnetically. Pattern Omnidirectional Max Input Power(W) 25 Frequency Range | Gain 698 – 960MHz | 2dBi; 1710 – 3800MHz | 5dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements 2 x 2 MIMO; No UHF Elements No GPS Frequency Range 1562-1612MHz LNA GAIN (dB) 26 Number of GPS Elements 1 Module; No Cable Length – LTE min: 1 (m) | 3.28 (ft); max: 3 (m) | 9.84 (ft) Cable length – GPS min: 1 (m) | 3.28 (ft); max: 3 (m) | 9.84 (ft) Cable Length – WIFI min: 1 (m) | 3.28 (ft); max: 3 (m) | 9.84 (ft) Cable Type (LTE) RG174 Cable Type (GPS) RG174 Cable Type (WIFI) RG174 Connector (WIFI) SMA Rev Pol Connector (GPS) SMA (m) Connector (LTE) SMA (m) Mounting Type Temp Magnetic Mounting Methods Magnetic IP Rating IP66 Technology GPS; WIFI MIMO; 4G/5G; WIFI; 5G; 2G/3G; 2G/3G/4G; GNSS; WIFI SISO

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LPAM-BC3G-26-1SP

Description: PANORAMA Compact Low Profile MIMO LTE antenna 2G/3G/4G/5G LTE cellular bands, Weatherproof 698-960/1710-3800MHz. The LP[G]AM-BC3G-26-[XSP] range has been designed to provide MiMo Cellular / LTE antenna function for IOT and M2M applications. The compact, robust low-profile housing is weatherproof and contains two antenna elements with effective isolation and correlation covering all current global cellular and LTE bands in freq. range 698-960/1710-3800MHz.The compact, robust low-profile housing is weatherproof and contains two antenna elements with effective isolation and correlation covering all current global cellular and LTE bands in freq. range 698-960/1710-3800MHz. The LG version includes an active GPS/GNSS/Galileo/Beidou antenna for applications that require position or timing function.The antenna can be fitted on a non-conductive panel if required* and offers easy, quick, secure, and weatherproof installation with the single hole mounting bush and acrylic adhesive sealing pad. Supplied with integrated 1m (3.3’) or 3m (10’) cable and SMA plug connectors, the antenna will offer plug and play connectivity with many different terminals. Pattern Omnidirectional Max Input Power(W) 20 Frequency Range | Gain 698 – 960MHz | ; 1710 – 2170MHz | 4.5dBi; 2500 – 3800MHz | 5dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements No UHF Elements No Cable Length – LTE min: 1 (m) | 3.28 (ft); max: 3 (m) | 9.84 (ft) Cable length – GPS min: 1 (m) | 3.28 (ft); max: 3 (m) | 9.84 (ft) Cable Type (LTE) RG174 Cable Type (GPS) RG174 Connector (GPS) SMA (m) Connector (LTE) SMA (m) Mounting Type Fixed Mast; Panel; Wall Mounting Methods Mast; Panel; Wall IP Rating IP66 Technology GPS; 4G/5G; 5G; 2G/3G; 2G/3G/4G; GNSS

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LPAM-BC3G-26-3SP

Description: PANORAMA Compact Low Profile MIMO LTE antenna 2G/3G/4G/5G LTE cellular bands, Weatherproof 698-960/1710-3800MHz. The LP[G]AM-BC3G-26-[XSP] range has been designed to provide MiMo Cellular / LTE antenna function for IOT and M2M applications. The compact, robust low-profile housing is weatherproof and contains two antenna elements with effective isolation and correlation covering all current global cellular and LTE bands in freq. range 698-960/1710-3800MHz.The compact, robust low-profile housing is weatherproof and contains two antenna elements with effective isolation and correlation covering all current global cellular and LTE bands in freq. range 698-960/1710-3800MHz. The LG version includes an active GPS/GNSS/Galileo/Beidou antenna for applications that require position or timing function.The antenna can be fitted on a non-conductive panel if required* and offers easy, quick, secure, and weatherproof installation with the single hole mounting bush and acrylic adhesive sealing pad. Supplied with integrated 1m (3.3’) or 3m (10’) cable and SMA plug connectors, the antenna will offer plug and play connectivity with many different terminals. Pattern Omnidirectional Max Input Power(W) 20 Frequency Range | Gain 698 – 960MHz | ; 1710 – 2170MHz | 4.5dBi; 2500 – 3800MHz | 5dBi Cellular LTE Elements 2 x 2 MIMO WIFI Elements No UHF Elements No Cable Length – LTE min: 1 (m) | 3.28 (ft); max: 3 (m) | 9.84 (ft) Cable length – GPS min: 1 (m) | 3.28 (ft); max: 3 (m) | 9.84 (ft) Cable Type (LTE) RG174 Cable Type (GPS) RG174 Connector (GPS) SMA (m) Connector (LTE) SMA (m) Mounting Type Fixed Mast; Panel; Wall Mounting Methods Mast; Panel; Wall IP Rating IP66 Technology GPS; 4G/5G; 5G; 2G/3G; 2G/3G/4G; GNSS

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: WM8E-BADEP3G-26-NJ

Description: PANORAMA Directional High Gain Antenna 2G/3G/4G, Wall/ Mast Mount, 698-960MHz, 1710-2700MHz, indoor and outdoor A versatile high gain directional antenna ideal for indoor and outdoor deployment, Panorama’s WM8E range allows businesses and individual users to boost or distribute 2G/3G and 4G signal from their router or repeater. The WM8E-BADEP3G-26-NJ supports 2G, 3G, 3G+ and 4G technologies including LTE, AMPS, PCS, GSM, UMTS & AWS with lower gain coverage of WIFI 2.4GHz and LTE 2.6GHz. The WM8E range is housed in impact resistant, UV light stabilised plastic. The features a heavy duty N female connector suitable for kitting with a range of cable extensions. Max Input Power(W) 50 Typical VSWR <2.5:1 Frequency Range | Gain 698 – 960MHz | 6.5dBi; 1710 – 2170MHz | 9dBi; 2400 – 2700MHz | 6dBi Cellular LTE Elements No WIFI Elements No UHF Elements No Number of GPS Elements No Operating Temperature -30°/ +70°C (-22.0°/ +158.0°F) Connector (LTE) N (f) Mounting Type Fixed Mast; Wall Mounting Methods Mast; Wall Technology 2G/3G; 2G/3G/4G

Brand: Generic

Category: IoT / LTE / QuWireless LTE Antenna Enclosures

SKU: DMM-7-38-2TS9

Description: Use the DMM-7-38 to ensure a strong 4G or 3.6GHz 5G connection and fast transfer speeds for your modem or router. It's unique 'X' design enables MiMo connectivity across a huge frequency range and with the options of desk or window mounting the antenna is ideal for use on the move. Supports 2x2 MiMo 4G and 3.6GHz 5G Desk, Window or Laptop Mount 2m cables This multiband portable antenna is designed to be compact and easy to use. It has feet which allow it to be used freestanding, a suction cup for window mounting, and clips for attachment to a laptop. The is a versatile and compact travel companion to ensure you have excellent signal in all situations.

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LGMQM4B-6-60-24-58

Description: PANORAMA DOME ANT 4x4 4G/5G 4x4WIFI GPS/GNSS-Blk

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LGMHM4B-6-60-24-58

Description: PANORAMA L[G]M[H]M4[B]-6-60[-24-58] | 4×4 MiMo 4G/5G, up to 6×6 MiMo WiFi + GPS/GNSS Vehicle Antenna The MAKO® 5G Dome is a range of high-performance 4×4 MiMo antennas covering 617-960/1710-6000MHz with optional GPS/GNSS and optional 2×2, 3×3 or 4×4, or 6×6 MiMo/Diversity at 2.4/5.0/7.2GHz. The MAKO® 5G Dome consists of up to 11 elements; four isolated high-performance antenna elements covering 617-960/1710-6000MHz offer MiMo/Diversity at cellular/LTE frequencies, up to 6 optional dual band elements covering 2.4 & 5.0/7.2GHz support MiMo/Diversity operation for WiFi and optional high-performance GPS/GNSS antenna with an integrated 26dB gain LNA and high-quality filtering offers unparalleled positioning accuracy. None of the antennas in this range require a metallic ground plane, and all maintain a high level of performance even when mounted on non-metallic surfaces. Designed for latest generation LTE Cat 18/20 routers and devices Low profile antenna with up to 11 functions in 1 4×4 MiMo 4G/5G LTE cellular, Optional GPS/GNSS & optional MiMo 2.4/7.2GHz in one housing Kits with extension cables available for a range of LTE routers Flame retardant cables compliant to UNECE R118 Pre-terminated antenna connectors fitted as standard Pattern Omnidirectional Max Input Power(W) 10 Frequency Range | Gain 617 – 960MHz | 4dBi; 1710 – 3800MHz | 8dBi; 4900 – 6000MHz | 9dBi Cellular LTE Elements 4 x 4 MIMO WIFI Elements No; 2 x 2 MIMO; 4 x 4 MIMO; 6 x 6 MIMO; 5 x 5 MIMO; 3 x 3 MIMO UHF Elements No GPS DATA GPS Frequency Range 1562-1612MHz LNA GAIN (dB) 26 Number of GPS Elements 1 Module; No MECHANICAL DATA Colour Black; White Height 80 (mm) | 3.15 (in) Diameter 180 (mm) | 7.09 (in) Operating Temperature -40°/ +80°C (-40.0°/ +176.0°F) CABLE DATA Cable Length – LTE min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable length – GPS min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft) Cable Length – WIFI min: 0.3 (m) | 0.98 (ft); max: 5 (m) | 16.4 (ft)

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LPAMM-7-27-24-58-3

Description: PANORAMA LO PRO MAG MIMO 2/3/4G+WIFI 3m SP

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LPM2W-24-72-2RPSP

Description: PANORAMA LOW PROF 2.4-7.2GHz 2m PORT LBL 2xRPSP ANT - WHT

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LG5AQM4-7-42

Description: PANORAMA Low Profile Housing Contains 4x 4G LTE / 5G NR elements covering 698-960/1427-4200MHz. 4X4 MiMo 4G/5G IOT Antenna PANORAMA MiMo antenna is designed to be a one size fits all solution for IOT applications. The robust low profile housing contains 4x 4G LTE / 5G NR elements covering 698-960/1427-4200MHz. Versions of the product also contain up to 4x optional WiFi elements supporting WiFi 6e 2.4/5.150-7.125GHz and optional L1 only or L1/L5 GPS/GNSS. The housing is constructed from robust, flame retardant, impact resistant plastic. The subtle, curved design makes the product harder to vandalise and the IK10 rating ensures that the product is suitable for use in tough environments and devices located in public areas. The housing is UV stable and approved to IP69K for ingress protection. The product is supplied with integrated low loss flame retardant cables approved to UN ECE R118 and fitted connectors offer plug and play connectivity for a huge range of devices. The Clam® can be installed on conductive or non-conductive panels without significant detriment to performance. ELECTRICAL DATA: Pattern Omnidirectional Max Input Power(W) 5 Typical VSWR <2.5:1 Frequency Range | Gain Check the part number table Cellular LTE Elements 4 x 4 MIMO WIFI Elements 4 x 4 MIMO; 2 x 2 MIMO; No UHF Elements No GPS DATA: GPS Frequency Range 1164-1189MHz/1559-1612MHZ; 1559-1612MHz LNA GAIN (dB) 30 / 26; 26 Number of GPS Elements 1 Module; No MECHANICAL DATA: Colour Black Length 175 (mm) | 6.89 (in) Width 118 (mm) | 4.65 (in) Height 56.9 (mm) | 2.24 (in) Operating Temperature -40°/ +85°C (-40.0°/ +185.0°F) CABLE DATA: Cable Length – LTE: 2 (m) | 6.56 (ft) Cable length – GPS: 2 (m) | 6.56 (ft) Cable Length – WIFI: 2 (m) | 6.56 (ft) TERMINATION DATA: Connector (WIFI) Reverse Polarity SMA; SMA Rev Pol Connector (GPS) SMA (m) Connector (LTE) SMA (m) MOUNTING DATA: Mounting Type Fixed Panel Mounting Methods: Panel

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LGM2-24-58-5RPSP

Description: PANORAMA Low Profile Omni-Directional Antenna 2x2 MIMO,1562-1612MHz, Dual band WiFi 2.4/5Ghz Antenna Reverse Polarity SMA,IK10. The L[G]M[X]-24-58 range has been designed to provide MiMo dual-band WiFI coverage in an ultra low profile package. The compact, robust low-profile housing contains up to four antenna elements with effective isolation and low correlation covering 2.4-2.5/4.9-6GHz. The antenna is designed to be panel mounted on vehicles or devices and can be fitted on a conductive or non-conductive panel. Supplied with integrated flame retardant CS32 cables (Compliant to UN ECE R118 and EN45545-2) and a halogen-free flame retardant radome the antenna is suitable for many environments and applications. The LGM variants have an integrated GPS/GNSS module with 26dB LNA gain. The antenna is available with a black or white radome. Pattern Omnidirectional Max Input Power(W) 10 Cellular LTE Elements No WIFI Elements 2 x 2 MIMO; 3 x 3 MIMO; 4 x 4 MIMO UHF Elements No GPS Frequency Range 1562-1612MHz LNA GAIN (dB) 26 Number of GPS Elements 1 Module; No Cable length – GPS 5 (m) | 16.40 (ft) Cable Length – WIFI 5 (m) | 16.40 (ft) Cable Type (GPS) FR CS32; RG174 Cable Type (WIFI) FR CS32 Connector (WIFI) Reverse Polarity SMA Connector (GPS) Reverse Polarity SMA; SMA (m) Mounting Type Fixed Panel Mounting Methods Panel IP Rating IP66; IK10; IP69K Cable Flammability EN45545-2 HL3; UN ECE R118; EN6722 Material Flammability UL746C-F1, UL94-V0 Technology GPS; WIFI MIMO; WIFI; 5G; GNSS

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LPMM4-6-60

Description: Panorama LPMM4-6-60 - 4G/5G 4x4 MiMo -Wht

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: PWB-24-58-RSMARV

Description: The PWB-24-58 antenna is a ground plane independent antenna covering 2.4 / 5.0GHz. Designed as an ‘on device’ antenna, the PWB-24-58 features an articulated SMA connector for flexible positioning and a sleek profile for low visual impact.

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: PWB-6-60-RSMAP

Description: PWB-6-60-RSMAP | Wide Band 4G/5G Terminal Paddle Antenna The PWB-6-60-RSMAP antenna is a ground plane independent antenna covering 617-960/1710-3800/4400-6000MHz. Supporting 2G/3G/4G and new 5G bands the PWB-6-60-RSMAP is the ideal one-size-fits-all solution for next-generation router and modem devices. Designed for terminals and routers, the PWB-6-60-RSMAP features an articulated sma connector with 3 step locking to set optimum angle.

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: SAB-309

Description: PANORAMA SAB-309 – Wall / Mast Mounting Bracket For use with the LPMM/LGMM range of low profile MiMo antennas, the SAB-309 provides a wall / pole mount option for LP[G]MM range antennas. The robust stainless steel bracket can be screw mounted to a wall or panel or fitted on a mast using the supplied mast clamps. This is a very easy, simple and quick solution that can permit LP[G]MM antennas to be mounted in elevated positions or in locations where a horizontal panel is not available. MOUNTING DATA Mounting Type Fixed Wall Mounting Methods Wall; Pole Technical Specification Material Stainless Steel Screw Fixings Not Supplied For Use With LPMM / LGMM

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: TK4SP2SPRVGPSME

Description: PANORAMA TRIAL KIT PADDLE 4X4 CELL 2x2WIFI GPSME 0.2m SP

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: WMM2G-6-60-5SP

Description: PANORAMA WALL MNT 2x2 MiMo GAIN ANT 4G/5G 5M SMA(m)

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: WMM4GG-6-60-5SP

Description: PANORAMA WALL MNT 4x4 MiMo GAIN ANT 4G/5G GNSS 5m SMA(m)

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: WMM29G-24-72-NJ

Description: PANORAMA WALL/MST MNT GAIN 2x2 MiMo 2.3-7.2GHz N(f)

Brand: PANORAMA

Category: IoT / LTE / Panorama Antennas

SKU: LPADM4-7-42

Description: PANORAMALOW PRO 4x4 4G/5G IOT BLK ANT 2x2 WiFi 2m CBL

Brand: QuWireless

Category: IoT / LTE / QuWireless LTE Antenna Enclosures

SKU: AX12S

Description:

Brand: Teltonika

Category: IoT / LTE / Teltonika Telematics

SKU: PPCB00000140

Description: Telematic OBD-II Connector Extension Cable Cable length - 50 cm Support for all light vehicles with OBDII socket

Brand: Teltonika

Category: IoT / LTE / Teltonika Accessories

SKU: PR320AUA

Description: Teltonika 2 Pin AU Power Supply, 250W - For TSW200, TSW202

Brand: Teltonika

Category: IoT / LTE / Teltonika Accessories

SKU: PR317AUA

Description: Teltonika 2 Pin AU Power Supply, 62W - For TSW200, TSW202

Brand: Teltonika

Category: IoT / LTE / Teltonika Accessories

SKU: PR3PRAU6

Description: Teltonika 2 Pin AU Power Supply, 9W - For TRB245, TRB255, TSW010, TSW114, TSW210, TSW304

Brand: Teltonika

Category: IoT / LTE / Teltonika Accessories

SKU: PR2FK20M

Description: Teltonika 4 Pin Power Cable with 4-Way Screw Terminal Input connector 4-way screw terminal Output connector 4-pin, 3mm pitch Cable 4x0.129 mm2 (26 AWG), 2000 mm RoHS Compliant ✔ Color coding 1 Red Power + 2 Black Ground - 3 Green Input/Output/NC 4 White Input/Output/NC

Brand: Teltonika

Category: IoT / LTE / Teltonika Telematics

SKU: FMC650

Description: Teltonika FMC650 is a direct successor to current most popular 4G PROFESSIONAL lineup device – FMC640. FMC650 has 4G (LTE Cat 1) network coverage including 2G (GSM) fallback compatibility. Device equipped with GNSS and LTE modules, external GNSS and LTE antennas. Separate GNSS module improves the accuracy of the track, making FMC650 more suitable for free flow electronic tolling system integration. Compared to FMC640 – FMC650 has a new processor that improves the devices computation power along with increased device internal memory it can be tailored to more specific use cases. Switchable CAN terminators that will allow you to use the device in CAN network with numerous nodes. Lastly, it can be powered via USB for easier configuration process. All the features that are supported by FMC640 is also supported by FMC650, therefore it will maximize your fleet efficiency with features like FMS CAN data (J1939), fuel CAN data (J1708), tachograph live data (K-Line), remote tachograph file download, various third party RS232 or RS485 devices support and Dual-SIM or eSIM compatibility. Terminal is suitable for applications like international logistics, refrigerated transport, agriculture, construction & mining, security & emergency services and even more.

Brand: Teltonika

Category: IoT / LTE / Teltonika Accessories

SKU: PR4MK04K

Description: Teltonika 4-PIN Plug With Contact Terminals

Brand: Teltonika

Category: IoT / LTE / Teltonika Accessories

SKU: PR5MEC21

Description: This 4-PIN power connector adapter allows you to easily access I/O functionality for compatible Teltonika Networks devices. It features a standard 4-PIN to 4-PIN power connection with an additional terminal for configurable digital inputs and outputs. TECHNICAL DATA GENERAL Input connector 4-pin, 3 mm pitch and 4-way screw terminal block Output connector 4-pin, 3 mm pitch Cable 4 x 0.20 mm² (24 AWG), 100 mm Screwdriver type Micro slotted Weight 15 g. *CONNECTION DATA Conductor cross section solid / flexible 0.14 - 0.50 mm² (26 - 20 AWG) Conductor cross section flexible, with ferrule, with plastic sleeve 0.25 - 0.30 mm² (23 - 22 AWG) Pinout 1 Pin: Power + 2 Pin: Ground - 3 Pin: Input/Output 4 Pin: Input/Output

Brand: Teltonika

Category: IoT / LTE / Teltonika Accessories

SKU: PR2PP10B

Description: Teltonika 4-PIN TO 4-PIN POWER CABLE

Brand: Teltonika

Category: IoT / LTE / Teltonika Accessories

SKU: PR2PD01B

Description: Teltonika 4-PIN TO BARREL SOCKET ADAPTER
