Brand: Lindy

Category: Cables and adapters / AV Cables / DisplayPort

SKU: 36920

Description: Lindy 0.5m DisplayPort to HDMI 10.2G Cable

Enhance your visual experience with the Lindy DisplayPort to HDMI® Adapter Cable. The cable is perfect for connecting your DisplayPort equipped PC or laptop to an HDMI® display, this cable delivers 4K UHD resolution up to 3840x2160 at 30Hz, ensuring crystal-clear video quality. Whether you're extending your desktop workspace for increased productivity or setting up a high-definition home or office display, the Lindy DisplayPort to HDMI® Adapter cable is perfect for the task at hand.

The adapter also supports uncompressed 7.1 audio and advanced audio formats such as DTS-HD Master Audio and Dolby TrueHD.

Please note: Audio output over HDMI® is dependent on your graphics card's support for audio output via DisplayPort.

Features:

• Connects a DisplayPort equipped device to a 4K UHD HDMI® display or projector
• Supports resolutions up to 3840x2160@30Hz
• Supports video mirroring and extended desktop modes
• Audio pass-through if supported by the video source
• 2 year warranty

Specifications:

Connectors

• Connector A: DisplayPort male
• Connector B: HDMI® Type A male
• Housing Material:
  • DisplayPort: PVC
  • HDMI®: ABS
• Connector Plating: Gold plated
• Pin Construction: Copper
• Pin Plating: Gold plated
• Dimensions (approx.) WxDxH:
  • DisplayPort: 37.6x21x12.3mm (1.48x0.83x0.48in)
  • HDMI®: 45x21.8x12.4mm (1.78x0.86x0.49in)

Cable Construction

• Length: 0.5m (1.64ft)
• Standard: HDMI® 1.4, DisplayPort 1.2
• Colour: Black
• Type: Round
• Jacket Diameter: 5.0mm (0.20in)
• Jacket Material: PVC
• Conductor Material: Copper
• Conductor Gauge: 28AWG
• Shielding: Aluminum Braid 85%

Specifications

• Supported Bandwidth: 10.2Gbps
• Maximum Resolution: 3840x2160@30Hz 4:4:4 8bit
• Nominal Attenuation: -
• Minimum Bend Radius: 50mm (1.97in)
• Operating Temperature: -10°C - 80°C (14°F - 176°F)
• Storage Temperature:  -20°C - 85°C (-4°F - 186°F)

Miscellaneous

• Packaging Type: Polybag
• Warranty (Years): 2
• Product Compliance: CE, UKCA, FCC, RoHS, REACH, California Proposition 65

Brand: Lindy

Category: Cables and adapters / AV Cables / DisplayPort

SKU: 38520

Description: Lindy 10m Fibre Optic Hybrid DisplayPort 2.0 UHBR10 Cable

Features

• Combines copper and fibre optic cable for a hybrid, long distance DisplayPort connectivity solution
• Supports resolutions up to 4K@144Hz, 8K@60Hz
• DP2.0 standard with UHBR10 support, 40Gbps bandwidth (4 lanes, 10Gbps per channel)
• Flexible and robust cable structure for any kind of installations
• 2-Year Warranty

Specifications

Connectors

• Connector A: DisplayPort (Male)
• Connector B: DisplayPort (Male)
• Housing Material: PVC
• Connector Plating: Gold Plated
• Pin Construction: Gold Plated
• Pin Plating: Gold Plated
• Dimensions (approx.) WxDxH: DP Connector: 19.8x47.8x12mm (0.78x1.88x0.47in)

Cable Construction

• Length: 10m (32.81ft)
• Standard: DisplayPort 2.0
• Colour: Black
• Type: Round
• Jacket Diameter: 4.0mm (0.16in)
• Jacket Material: PVC
• Conductor Material: Fiber and Copper
• Conductor Gauge: 24AWG
• Shielding: -

Specifications

• Supported Bandwidth: 40Gbps
• Maximum Resolution: 7680x4320@60Hz 4:2:0 10bit, 3840x2160@144Hz 4:4:4 10bit
• Nominal Attenuation: ≤10dB/km@850nm, ≤8dB/km@1300nm
• Minimum Bend Radius: 50mm (1.97in)
• Operating Temperature: -10°C - 60°C (14°F - 140°F)
• Storage Temperature: -20°C - 70°C (-4°F - 158°F)

Miscellaneous

• Packaging Type: Carton Box
• Warranty (Years): 2
• Certificated: CE, UKCA, FCC, RoHS, REACH & California Proposition 65

Brand: Lindy

Category: Cables and adapters / AV Cables / DisplayPort

SKU: 38521

Description: Lindy 15m Fibre Optic Hybrid DisplayPort 2.0 UHBR10 Cable

Features

• Combines copper and fibre optic cable for a hybrid, long distance DisplayPort connectivity solution
• Supports resolutions up to 4K@144Hz, 8K@60Hz
• DP2.0 standard with UHBR10 support, 40Gbps bandwidth (4 lanes, 10Gbps per channel)
• Flexible and robust cable structure for any kind of installations
• 2-Year Warranty

Specifications

Connectors

• Connector A: DisplayPort (Male)
• Connector B: DisplayPort (Male)
• Housing Material: PVC
• Connector Plating: Gold Plated
• Pin Construction: Gold Plated
• Pin Plating: Gold Plated
• Dimensions (approx.) WxDxH: DP Connector: 19.8x47.8x12mm (0.78x1.88x0.47in)

Cable Construction

• Length: 10m (32.81ft)
• Standard: DisplayPort 2.0
• Colour: Black
• Type: Round
• Jacket Diameter: 4.0mm (0.16in)
• Jacket Material: PVC
• Conductor Material: Fiber and Copper
• Conductor Gauge: 24AWG
• Shielding: -

Specifications

• Supported Bandwidth: 40Gbps
• Maximum Resolution: 7680x4320@60Hz 4:2:0 10bit, 3840x2160@144Hz 4:4:4 10bit
• Nominal Attenuation: ?10dB/km@850nm, ?8dB/km@1300nm
• Minimum Bend Radius: 50mm (1.97in)
• Operating Temperature: -10°C - 60°C (14°F - 140°F)
• Storage Temperature: -20°C - 70°C (-4°F - 158°F)

Miscellaneous

• Packaging Type: Carton Box
• Warranty (Years): 2
• Certificated: CE, UKCA, FCC, RoHS, REACH & California Proposition 65

Brand: Lindy

Category: Cables and adapters / AV Cables / DisplayPort

SKU: 40922

Description: Lindy 2m Active Mini DisplayPort to HDMI Cable with HDR

Specifications:

• Connector A: Mini DisplayPort Male
• Connector B: HDMI Type A Male
• Housing material: ABS
• Connector plating: 24K Gold 1µm
• Pin construction: Brass
• Pin Plating: 24K Gold 3µm
• Dimensions:
• Mini DisplayPort: 18.6x11.5x9.3mm
• HDMI: 45.1x21.8x12.2mm
• Length: 2m
• Standard: HDMI 2.0, Mini DisplayPort 1.2
• Colour: Black
• Type: Round
• Jacket Diameter: 5mm
• Jacket Material: PVC
• Conductor Material: Tinned copper
• Conductor Gauge: 32AWG
• Shielding: Copper braid, 85% AL/MG coverage
• Supported Bandwidth: 18Gbps
• Maximum Resolution: 4096x2160@60Hz 4:4:4 8bit, 4096x2160@60Hz 4:2:2 12bit
• Nominal Attenuation: -12dB@825-2475MHz, -20dB@ 2475-4125MHz, -25dB@4125-5100MHz
• Minimum Bend Radius: 60mm
• Operating Temperature: -20C - 70C
• Storage Temperature: -25C - 85C
• Packaging Type: Polybag
• Warranty: 2-year
• Certificated: CE, FCC, RoHS & REACH, California Proposition 65

Features:

• Connect a Mini DisplayPort-equipped device to a 4K HDMI display or projector
• Supports high-quality resolutions up to 4K@60Hz
• High Dynamic Range support provides deeper blacks, brighter whites and a wider colour gamut
• Active chipset for enhanced compatibility with various graphic cards
• 2-year warranty
